神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (042-01-1) - CLEANER ASSY, AIR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
202 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN11P00028F1 | [1] | Air | |
| 1. | YN11P00029F1 | [1] | CLEANER | KOBAssy, Air |
| 1-1. | YN11P00029S001 | [1] | NSS Air cleaner Housing | |
| 1-2. | YN11P00029S002 | [1] | ELEMENT | KOBFilter (inner) Superseded by part number: 87683001 |
| 1-3. | YN11P00029S003 | [1] | AIR FILTER | KOBFilter (outer) Superseded by part number: KBH0921 |
| 1-4. | YN11P00029S004 | [1] | COVER ASSY | KOB |
| 1-5. | EB11P00001S005 | [1] | VALVE | KOBAssy Superseded by part number: YW11P00004S004 |
| 1-6. | YN11P00029S006 | [1] | O-RING | KOB |
| 1-7. | EB11P00001S006 | [1] | ADAPTER | KOB |
| 1-8. | YR11P00008S005 | [1] | INDICATOR | KOB Superseded by part number: LV11P01017F1 |
| 1-9. | EB11P00001S008 | [1] | LABEL | KOB |
| 2. | YN11P01118P1 | [1] | HOSE | KOBAir |
| 3. | YN11P01120P1 | [1] | HOSE | KOBAir |
| 4. | YN11P01126P1 | [1] | PLATE | KOB |
| 5. | ZC16X12200 | [1] | CLIP | KOB |
| 6. | ZC16X10000 | [2] | CLIP | KOB |
| 7. | ZC16X07000 | [1] | CLIP | KOB |
| 8. | ZM73C10025 | [8] | BOLT,M10x25mm - Course Thread | KOBSems |
