神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (120-01-2) - CONTROLS, OPERATORS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
410 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00134F1 | [1] | (See Fig No.125-01-1) | |
| . . | YN03M01870F1 | [1] | GRIP | KOBGrip Assy (See Fig No.127-01-1) |
| . . | YN50E00018F1 | [1] | Instal (See Fig No.129-01-1) | |
| . . | YN50M00013F1 | [1] | CONTROL LEVER | KOBPropel (See Fig No.138) |
| . . | YN55M00003F1 | [1] | FLOOR MAT | KOBPedal Assy (See Fig No.138) Superseded by part number: YN26M00064P1 |
| . . | YN54E00006F1 | [1] | Instal (See fig no. 129-01-1) | |
| . . | YN12P01163F1 | [1] | CLAMP | KOB(See fig no. 132-01-1) |
| . . | YN25M01180F1 | [1] | ARMREST | KOBArm (See fig no. 132-01-1) |
| . . | YN03M00137F1 | [1] | Operators | |
| 1. | YN03M01859P2 | [2] | SUPPORT | SM |
| 2. | YN26M00065P1 | [1] | FOOT BOARD | SMMat |
| 4. | YN03M01943F1 | [1] | GUARD | SMCover Assy, Serial Range: YQ11-06001-YQ11-06260 Superseded by part number: YN03M01943F2 |
| . . | YN03M01943F2 | [1] | COVER ASSY | KOB, Start Serial: YQ11-06261 |
| 5. | YN03M01945F1 | [1] | GUARD | SMCover Assy |
| 6. | YN03M01946F1 | [1] | GUARD | SMCover Assy |
| 7. | YN25M01168P1 | [1] | SUPPORT | SMStand, Seat |
| 8. | YN25M01161F1 | [1] | GUIDE | SMRail Assy |
| 9. | YN20M01356P1 | [1] | DIFFUSER | KOBGrille |
| 10. | ZM73C10020 | [4] | BOLT,M10x20mm - Course Thread | KOBSems |
| 11. | ZS28C08016 | [4] | SCREW,Hex Socket Head, M8 x 16mm | KOBCap |
| 12. | ZW26K08000 | [4] | LOCK WASHER | KOB |
| 13. | ZW16P08000 | [4] | WASHER | KOB |
| 14. | ZS28C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBCap |
| 15. | YN02C02055P1 | [1] | TRAY | KOBAsh |
| 16. | ZM66C06016 | [9] | BOLT | KOBSems |
| 17. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBSems |
| 18. | YN20M01643P1 | [1] | SPRING | SM, Start Serial: YQ11-06106 Superseded by part number: YN20M01643P2 |
| 19. | YT03M01222P1 | [1] | GROMMET | KOB, Start Serial: YQ11-06488 |
