神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (120-60-1) - CONTROLS, OPERATORS (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00135F1 | [1] | Controls,Operators (See Fig No. 120) | |
| . . | YN03M00137F1 | [1] | Controls,Operators (See Fig No. 125) | |
| . . | YN03M00138F1 | [1] | CONTROL | KOBox Assy (See Fig No. 127) |
| . . | YN03M01870F1 | [1] | GRIP | KOBAssy (See Fig No. 129) |
| . . | YN50E00018F1 | [1] | Switch Instal (See Fig No. 138) | |
| . . | YN50M00013F1 | [1] | CONTROL LEVER | KOBLever Assy,Propel (See Fig No. 129) |
| . . | YN54E00006F1 | [1] | Radio Instal (See Fig No. 138) | |
| . . | YN12P01163F1 | [1] | CLAMP | KOBClamp Assy (See Fig No. 129) |
| . . | YN25M01180F1 | [1] | ARMREST | KOBArm Rest (See Fig No. 132) |
| . . | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBPedal Assy (See Fig No. 132) |
| 1. | ZM73C08020 | [1] | BOLT,M8x20mm - Course Thread | KOBMat, Floor |
| 2. | YN03M01684P1 | [1] | BRACKET | SMPedal |
| 3. | YN03M01858P1 | [1] | RUBBER PEDAL PAD | SM |
| 4. | YN03M01852P1 | [1] | PEDAL | SMLock Assy |
| 5. | YN26M00066P1 | [2] | FOOT BOARD | SMSems-Bolt |
| 6. | YN55M00004F1 | [2] | PEDAL | KOBSems-Bolt |
