神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (125-01-1) - CONTROL BOX ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1004 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00138F1 | [1] | CONTROL | KOBBox Assy |
| 1. | YN03M01872P1 | [1] | BRACKET | KOBAssy Superseded by part number: YN03M02173P1 |
| 2. | YN03M01880P1 | [1] | CONTROL | KOBBox |
| 3. | YN03M01886P1 | [1] | BRACKET | SM |
| 4. | YN03M01889P1 | [1] | SUPPORT | SMControl Box Superseded by part number: YN03M01889P3 |
| 5. | YN03M01898P2 | [1] | LEVER | SMAssy |
| 6. | YN20M01643P1 | [1] | SPRING | SM, Serial Range: YQ11-06001-YQ11-06105 Superseded by part number: YN20M01643P2 |
| 7. | YN50S00041F1 | [1] | LIMIT SWITCH | SM(2 prong switch) |
| 8. | YN03M01904P1 | [1] | SHAFT | SM |
| 9. | YN03M01905P1 | [1] | SHAFT,20mm OD x 108mm L | SM |
| 10. | YN03M01906P1 | [1] | STOP LOCK | SMStopper |
| 11. | YN03M01907P1 | [1] | NUT | SM Superseded by part number: ZN18F10006 |
| 12. | YN03M01908P1 | [1] | SCREW | SMBolt Superseded by part number: YN03M01908P2 |
| 13. | ZM73C08020 | [6] | BOLT,M8x20mm - Course Thread | KOBSems |
| 15. | YN03M01911P1 | [1] | BUSHING | SM |
| 16. | YN03M01912P1 | [1] | WASHER,11mm ID x 30mm OD x 2mm Thk | SM |
| 17. | YN03M01913P1 | [1] | RING | SMRetaining |
| 18. | YN03M01914P1 | [3] | RING | SMRetaining |
| 19. | YN03M01915P1 | [1] | WASHER | SM |
| 20. | YN03M01916P1 | [2] | RING | SMRetaining |
| 21. | YN03M01917P1 | [1] | RING | SMRetaining |
| 22. | YN03M01918P1 | [2] | BOLT | SMBolt |
| 23. | YN03M01919P1 | [2] | NUT | SM |
| 24. | YN03M01920P1 | [1] | SHAFT,10mm OD x 46.85mm L | SM |
| 25. | YN03M01921P1 | [2] | SCREW | SMBolt |
| 26. | YN03M01922P1 | [2] | WASHER | KOB Superseded by part number: ZW16K06000 |
| 27. | YN03M01924P1 | [1] | PLATE | KOB |
| 28. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBSems |
