神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (150-01-2) - CONTROL LINES, VALVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
430 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN64H00216F1 | [1] | Control, Valve | |
| . . | YN64H00219F1 | [1] | Control, Valve | |
| A1. | YN35V00047F1 | [1] | HYDRAULIC VALVE | SMAssy, Solenoid Superseded by part number: YN35V00047F3 |
| A3. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB |
| A4. | 2420R349D055 | [1] | HOSE,6.35mm ID x 550mm L | KOB |
| A5. | 2420R349D115 | [2] | HOSE,1150.00 mm | KOB Superseded by part number: HX21E04115DX |
| A6. | 2420R349D185 | [1] | HOSE,6.35mm ID x 1850mm L | KOB |
| A7. | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| A8. | 2420R537D090 | [1] | FLEXIBLE HOSE,9.60mm ID x 900mm L | KOB |
| A9. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB |
| A10. | 2420R537D150 | [1] | FLEXIBLE HOSE,9.60mm ID x 1500mm L | KOB Superseded by part number: HX21E06150DX |
| A11. | 2420R537D270 | [1] | FLEXIBLE HOSE,9.60mm ID x 2700mm L | KOB |
| A12. | 2420R537D290 | [1] | HOSE,9.53mm ID x 2900mm L | KOB |
| A13. | 2420R537D260 | [1] | HOSE,9.60mm ID x 2600mm L | KOB |
| A14. | ZH22X04000 | [5] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A15. | ZH22X06000 | [2] | HYD CONNECTOR | KOB |
| A16. | ZH32X04000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| A17. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| A18. | 2444Z2336 | [1] | TEE | KOBTee |
| A19. | HH25X06006GA | [1] | HYD CONNECTOR | KOBConnector |
| A20. | HH35X06006G3 | [1] | ELBOW | KOB |
| A21. | LC64H01104P1 | [1] | CLAMP | KOB |
| A22. | ZM73C08030 | [2] | BOLT,M8x30mm - Course Thread | KOBSems |
| A23. | ZM73C10020 | [3] | BOLT,M10x20mm - Course Thread | KOBSems |
| A24. | ZM73C10025 | [1] | BOLT,M10x25mm - Course Thread | KOBSems |
| A25. | ZS18C10090 | [1] | SCREW,Hex, M10 x 90mm | KOBCap |
| A26. | ZW16H10000 | [1] | WASHER | KOB |
| A27. | EW02E01015D4 | [3] | CLIP | KOB |
| A28. | YN13E01375P1 | [4] | CLIP,M8 x 8.20mm Shank | KOB |
| A29. | PY01P01043D8 | [4] | CABLE TIE,102mm L | KOB |
| . . | YN64H00220F1 | [1] | Control, Valve | |
| B1. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
