神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (160-60-2) - CONTROL LINES, REMOTE (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
215 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN68H00135F1 | [1] | REMOTE CONTROL | KOBControl Lines, Remote |
| A1. | YN30V00080F1 | [1] | VALVE | KOBAssy, Pilot |
| A2. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB |
| A3. | 2420R349D160 | [1] | HOSE,6.35mm ID x 1600mm L | KOB |
| A4. | 2420R349D365 | [1] | HOSE ASSY. | KOB |
| A5. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB |
| A6. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A7. | ZH32X04000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| A8. | ZE72X04000 | [1] | PLUG | KOB |
| A9. | YX52S00013P1 | [1] | SENSOR | SMPress (L.P), Serial Range: YQ11-06001-YQ11-06105 Superseded by part number: LC52S00019P1 |
| . . | LC52S00019P1 | [1] | SENSOR | SMPress Incls. O-Ring ZD12P01100, Start Serial: YQ11-06106 |
| A9-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| A10. | HM83C10030G1 | [2] | BOLT | KOBSems |
| A11. | ZH22X04006 | [1] | HYD CONNECTOR | KOB |
| . . | YN64H00225F1 | [1] | CONTROL BLOCK | KOBLines |
| B1. | YN64H01292P1 | [1] | BLOCK | KOB |
| B2. | 2420R349D110 | [2] | HOSE,1100.00 mm | KOB Superseded by part number: HX21E04110DX |
| B3. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| B4. | ZH42X04006 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| B5. | HM83C10030G1 | [2] | BOLT | KOBSems |
| B6. | YN64H01288P1 | [1] | CLAMP | KOB |
| B7. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| B8. | LC64H00090F1 | [1] | CONTROL | KOBControl |
| C1. | YN64H01337P1 | [1] | BLOCK | SM |
| C2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBSems |
