| . . | YN21C00092F1 | [1] | Instal | |
| . . | YN21C00094F1 | [1] | GUARD | KOBInstal (See Fig No.242-01-1) |
| . . | YN21C00095F1 | [1] | Instal (See Fig No.244-01-1) | |
| . . | YN21C00096F1 | [1] | Instal (See Fig No.246-01-1) | |
| . . | YN21C00150F1 | [1] | Instal | |
| . . | YN21C00093F1 | [1] | Instal | |
| 1. | YN21C03063F1 | [1] | TOOL BOX | KOB |
| 1-1. | YN21C03354P2 | [1] | BOX | KOB Superseded by part number: YN21C03354P3 |
| 1-2. | YN21C03023P1 | [1] | COVER | KOB Superseded by part number: YN21C03023P2 |
| 1-2C. | YN21C02202P1 | [1] | LOCK | SM |
| 1-2D. | YN21C02333P1 | [2] | HINGE | KOB |
| 1-3. | YN21C02821P1 | [1] | STAY | KOBStay |
| 1-4. | ZW16P06000 | [1] | WASHER | KOB |
| 1-5. | 2419R9D1 | [1] | COTTER PIN | KOBSnap |
| 1-6. | YJ21C01079D1 | [3] | INSULATING PANEL | KOBTrim |
| 1-8. | ZM73C12025 | [2] | BOLT,M12x25mm - Course Thread | KOBSems |
| 1-9. | YN21C03253D1 | [2] | SPACER | KOBTrim |
| 1-10. | YN21C03253D2 | [1] | SPACER | KOBTrim |
| 2. | YN21C03089P1 | [1] | COVER | KOB Superseded by part number: YN21C04619P1 |
| 3. | YN21C03104F1 | [1] | GUARD | KOBAssy |
| 3-1. | YN21C03247P1 | [1] | GUARD | KOB Superseded by part number: YN21C03247P2 |
| 3-2. | LC21C01040P1 | [1] | INSULATING PANEL | KOBInsulation |
| 4. | YN21C03347P1 | [1] | BEAM | KOB |
| 5. | YN21C03239P2 | [1] | GUARD | KOB |
| 6. | YN21C02864P1 | [1] | GUARD | KOB |
| 7. | YN21C02902P3 | [1] | STAY | KOBStay, Serial Range: YQ11-06001-YQ11-06478 Superseded by part number: YN21C02902P4 |
| 8. | YN21C03238P1 | [1] | PLATE | KOB |
| . . | YN21C02902P4 | [1] | STAY | KOBStay, Start Serial: YQ11-06479 |
| 10. | YN21C03341P1 | [1] | PILLAR | KOB |
| 11. | YN21C03329P2 | [1] | PILLAR | KOB |
| 12. | YN21C03017P1 | [1] | PILLAR | KOB Superseded by part number: YN21C03017P2 |
| 13. | YN21C03351F1 | [1] | GUARD | KOBAssy |
| 13-1. | YN21C03352P1 | [1] | GUARD | KOB |
| 13-2. | YN21C03340P1 | [1] | FOAM INSULATION | KOB |
| 14. | YN21C02953P2 | [1] | GUARD | KOB |
| 15. | YN21C03332P1 | [1] | GUARD | KOB |
| 16. | YN21C02599F1 | [1] | GUARD | KOBAssy |
| 16-1. | YN21C03343P2 | [1] | GUARD | KOB Superseded by part number: YN21C03343P3 |
| 16-2. | YN21C02724P1 | [1] | FOAM INSULATION | KOB |
| 17. | YN21C03039P2 | [1] | GUARD | KOB |
| 18. | YN21C02960F1 | [1] | COVER ASSY | KOBAssy |
| 18-1. | YN21C02961P1 | [1] | COVER | KOB |
| 18-2. | YN21C03141P1 | [1] | RUBBER BAND | KOB |
| 19. | YN21C03498F1 | [1] | COVER ASSY | KOBAssy |
| 19-1. | YN21C02980P3 | [1] | GUARD | KOB |
| 19-2. | 2420R372D8 | [2] | GROMMET | KOB |
| 20. | YN21C02423P1 | [1] | PLATE | KOB |
| 21. | YN21C02410P1 | [1] | BRACKET | KOB |
| 22. | YN21C01716P1 | [1] | PLATE | KOB |
| 23. | YN21C02747P1 | [1] | SPRING | KOB |
| 24. | YN21C02748P1 | [1] | SPRING | KOB |
| 25. | YN21C02425P1 | [2] | STAY | KOBStay |
| 26. | YN21C03334P1 | [1] | PLATE | KOB, Serial Range: YQ11-06001-YQ11-06052 Superseded by part number: YN21C04124P1 |
| . . | YN21C03777P1 | [1] | PLATE | SM, Start Serial: YQ11-06053 Superseded by part number: YN21C04124P1 |
| 27. | YN21C03335P1 | [1] | PLATE | KOB, Serial Range: YQ11-06001-YQ11-06052 Superseded by part number: YN21C04123P1 |
| 28. | YN21C03350P1 | [1] | STAY | KOBStay |
| . . | YN21C03778P1 | [1] | PLATE | SM, Start Serial: YQ11-06053 Superseded by part number: YN21C04123P1 |
| 29. | 2419R9D6 | [1] | PIN | KOBSnap |
| 30. | ZW16P16000 | [1] | WASHER | KOB |
| 31. | YN21C03212P1 | [4] | STOP | KOB |
| 32. | ZN18F10008 | [4] | NUT | KOB |
| 33. | ZS18C12025 | [4] | SCREW,Hex, M12 x 25mm | KOBCap |
| 34. | 2418T10357 | [6] | WASHER | KOB Superseded by part number: 2418T12345 |
| 35. | ZM32C12025 | [4] | BOLT | KOBSems |
| 36. | YN21C01395P1 | [4] | WASHER | KOB |
| 37. | YN21C01396P1 | [4] | WASHER | KOB |
| 38. | YN21C02138P1 | [2] | WASHER | KOB |
| 39. | YN21C02147P1 | [2] | WASHER | KOB |
| 40. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOBSems |
| 41. | ZM73C12025 | [46] | BOLT,M12x25mm - Course Thread | KOBSems |
| 42. | ZM73C12030 | [10] | BOLT,M12x30mm - Course Thread | KOBSems |
| 43. | ZM73C12040 | [4] | BOLT,M12x40mm - Course Thread | KOBSems |
| 46. | 2416T6289D6 | [1] | STAY | KOBStay |
| 47. | 2419R9D2 | [1] | COTTER PIN | KOBSnap |
| 48. | ZN18C10008 | [2] | NUT | KOB |
| 49. | ZW16H10000 | [2] | WASHER | KOB |
| 50. | 2418T21942 | [3] | WASHER | KOB |
| 51. | ZM73C12035 | [1] | BOLT,M12x35mm - Course Thread | KOBSems |
| 52. | YN21C03776P1 | [1] | SHIM | SM, Start Serial: YQ11-06053 Superseded by part number: 84529272 |
