神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (250-01-1) - COVER ASSY, UNDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
887 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN24C00035F1 | [1] | COVER ASSY | KOBUnder |
| 1. | YN24C01286P3 | [1] | COVER | KOB |
| 2. | YN24C01257P3 | [1] | COVER | KOB |
| 3. | YN24C01310P1 | [1] | GUARD | SMCover |
| 4. | YN24C01288P1 | [1] | COVER | KOB |
| 5. | YN24C01311F1 | [1] | COVER ASSY | KOB |
| 5-1. | YN24C01312P1 | [1] | COVER | KOB |
| 5-2. | 2427P1836D14 | [1] | WEATHERSTRIP | KOB |
| 5-3. | 2427P1836D5 | [1] | EXTRUSION | KOBStrip, Weather |
| 5-4. | PM21C01152D5 | [2] | WEATHERSTRIP | KOB |
| 6. | YN24C01284F1 | [1] | COVER ASSY | KOB Superseded by part number: YN24C01335F1 |
| 6-1. | YN24C01285P1 | [1] | COVER | KOB Superseded by part number: LQ24C01177P1 |
| 6-2. | 2427P1836D25 | [2] | WEATHERSTRIP | KOB |
| 6-3. | 2427P1836D19 | [2] | WEATHERSTRIP | KOB |
| 7. | YN24C01266F1 | [1] | COVER ASSY | KOB |
| 7-1. | YN24C01261P1 | [1] | COVER | KOB |
| 7-2. | PM21C01136DR | [1] | WEATHERSTRIP | KOB |
| 8. | YN24C01262P1 | [1] | COVER | KOB |
| 9. | ZM73C12030 | [24] | BOLT,M12x30mm - Course Thread | KOBSems |
| 10. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOBSems |
