| .. | YN20M00104F1 | [1] | Air | |
| 1. | R18T0026D87 | [1] | HOSE | KOB |
| 2. | R18T0026D36 | [1] | HOSE | KOB |
| 3. | YN20M01698P1 | [2] | BRACKET, SUPPORTING | KOB, Serial Range: YQ11-06001-YQ11-06419 Superseded by part number: YN20M01698P2 |
| 3. | YN20M01698P2 | [2] | BRACKET | KOB, Start Serial: YQ11-06420 |
| 4. | YN20M01494D1 | [1] | BELT | KOBV-belt (COG B66) |
| 5. | ZC16X02000 | [4] | CLIP | KOB |
| 6. | ZM73C10025 | [5] | BOLT,M10x25mm - Course Thread | KOBSems |
| 7. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBSems |
| 8. | ZM73C08020 | [9] | BOLT,M8x20mm - Course Thread | KOBSems |
| 9. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBCap |
| 10. | ZW16P08000 | [6] | WASHER | KOB |
| 11. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBCap, Serial Range: YQ11-06001-YQ11-06070 |
| 11. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBCap, Start Serial: YQ11-06071 |
| 12. | YN20M01427DA | [1] | PROTECTIVE SLEEVE | KOB |
| 13. | YN20M01046DT | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1500.00mm | KOBProtective Plastic |
| 14. | LS21P01001DW | [1] | TUBE | KOB |
| 15. | YN20M01094DW | [1] | RIGID TUBE | KOB |
| 16. | YN20M01551P1 | [1] | BRACKET | KOB, Serial Range: YQ11-06001-YQ11-06070 |
| 16. | YN20M01682P1 | [1] | BRACKET | KOB, Start Serial: YQ11-06071 |
| 17. | 2418Z1333D35 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1800mm Length | KOBProtective Plastic |
| 18. | YN20M01492D5 | [1] | HOSE | KOB |
| 20. | ZC16X02400 | [2] | CLIP | KOB |
| 21. | YN20M01545P2 | [1] | BRACKET | KOB, Serial Range: YQ11-06001-YQ11-06070 Superseded by part number: YN20M01677P1 |
| 21. | YN20M01677P1 | [1] | BRACKET | KOB, Start Serial: YQ11-06071 |
| 22. | ZM73C10040 | [2] | BOLT,M10x40mm - Course Thread | KOBSems |
| 23. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBSems |
| 24. | ZC48X24014 | [3] | CLIP | KOB |
| 25. | PY01P01043D4 | [16] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 27. | YN20M00105F1 | [1] | CONDITIONING UNIT | KOBAssy, Air (See Fig.290-01-1), Serial Range: YQ11-06001-YQ11-06070 Superseded by part number: YN20M00140F1 |
| 27. | YN20M00113F1 | [1] | AIR CONDITIONER | KOBAssy, (See Fig No.290-01-1), Serial Range: YQ11-06071-YQ11-06356 Superseded by part number: YN20M00140F1 |
| 27. | YN20M00118F1 | [1] | AIR CONDITIONER | KOBAssy, (See Fig No.290-01-1), Start Serial: YQ11-06357 Superseded by part number: YN20M00140F1 |
| 30. | YN20M01468P1 | [1] | PANEL | SMAir Conditioner Climate Control, Serial Range: YQ11-06001-YQ11-06298 Superseded by part number: YN20M01468P4 |
| 30. | YN20M01468P2 | [1] | PANEL | SMAir Conditioner Climate Control, Serial Range: YQ11-06299-YQ11-06356 Superseded by part number: YN20M01468P4 |
| 30. | YN20M01468P3 | [1] | PANEL | SMAir Conditioner Climate Control, Serial Range: YQ11-06357-YQ11-06512 Superseded by part number: YN20M01468P4 |
| 30. | YN20M01468P4 | [1] | PANEL | SMAir Conditioner Climate Control, Start Serial: YQ11-06513 |
| 32. | YX91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOBAssy, Air (See Fig No.294-01-1) |
| 32. | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOB200-8, SK210D-8, Both S/N YN11-45001, SK210DLC-8, SK210LC-8, Both S/N YQ11-06001, All EXCAVATOR |
| 32. | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 33. | YN20M01559F1 | [1] | PULLEY | KOBAssembly (Includes Tensioner Bolt), Serial Range: YQ11-06001-YQ11-06298 Superseded by part number: YN20M01696F1 |
| 33. | YN20M01696F1 | [1] | PULLEY,98mm OD | SMAssembly (Includes Tensioner Bolt), Start Serial: YQ11-06299 |
| 34. | YN20M01354P1 | [1] | CONDENSER | KOB, Serial Range: YQ11-06001-YQ11-06070 |
| 34. | YN20M01675P1 | [1] | CONDENSER | SM, Start Serial: YQ11-06071 |
| 35. | YN96V00024F1 | [1] | AERATOR | KOBDrier Assy, Air (See Fig No.292-01-1) Superseded by part number: YN96V00042F1 |
| 39. | YN50V01015P3 | [1] | CAB FILTER | SMAir-con, Filter (outer) Superseded by part number: YN50V01015P3P |
| 40. | YN52S00044P1 | [1] | SENSOR | SM |
| 49. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
| 50. | LC20M01126P1 | [1] | ELEC CONNECTOR | KOB |
| 51. | YN20M01597P1 | [1] | BRACKET | KOB |
| 52. | ZC46X22011 | [1] | CLIP | KOB |
| 53. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| 54. | YN20M01514P1 | [1] | GROMMET | SMGrommet |
| 58. | 2418Z1333D13 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 100mm Length | KOBProtective Plastic |
| 59. | 2432R233D3 | [1] | CLIP | KOB |
| 55. | YN20M01544P1 | [1] | GASKET | SMGrommet, Serial Range: YQ11-06001-YQ11-06070 Superseded by part number: YN20M01676P1 |
| 55. | YN20M01676P1 | [1] | GROMMET | SMGrommet, Start Serial: YQ11-06071 |
| 60. | ZN18C06005 | [4] | NUT | KOB |
| 61. | YN20M01701P1 | [4] | WASHER | KOB |
| 62. | YN20M01702P1 | [4] | WASHER | KOB |
| 63. | YN20M01703P1 | [4] | RUBBER SEAL | SMRubber |
