神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (290-01-1[1]) - CONDITIONER ASSY, AIR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
498 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20M00105F1 | [1] | CONDITIONING UNIT | KOBAir Superseded by part number: YN20M00140F1 |
| 1. | YN20M00107F1 | [1] | AIR CONDITIONER | SMAIR CONDITIONING Assy, See Page 298 Superseded by part number: YT20M00022F4 |
| 2. | LC20M01014D2 | [2] | HOSE,11mm ID x 360mm L | KOB |
| 3. | 24100U1176S5 | [2] | CLAMP | KOB |
| 4. | YT20M00009S005 | [1] | BOLT | KOBCap |
| 5. | YN50V01014P1 | [1] | CAB FILTER,124mm W x 491.5mm L | SMAir-Con, (Inner) Superseded by part number: YN50V01014P1P |
| 6. | YN20M01594F1 | [1] | TUBE | KOBAssy |
| 6-2. | 2445Z1604D5 | [1] | O-RING | KOB |
| 6-3. | 2445Z1604D6 | [1] | O-RING | KOB |
