神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (294-01-1) - COMPRESSOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
272 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOBAssy |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOB200-8, SK210D-8, Both S/N YN11-45001, SK210DLC-8, SK210LC-8, Both S/N YQ11-06001, All EXCAVATOR |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 1. | LC91V00001S002 | [1] | PLATE | KOBCore |
| 2. | YN91V01001S002 | [1] | PLATE | KOB |
| 3. | YN91V01001S003 | [1] | ROTOR | KOB |
| 4. | LC91V00001S004 | [1] | ACCESSORIES | KOB |
| 5. | YN91V01001S005 | [1] | COVER | KOB |
| 6. | YN91V01001S006 | [1] | COVER | KOB |
| 7. | YN91V01001S007 | [1] | RING | KOBAssy |
