神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (298-01-2) - CONDITIONER ASSY, AIR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
912 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 47. | YN20M00107S047 | [1] | LEVER | SM(For F1, F2 ONLY) Superseded by part number: YN20M00107S090 |
| . . | YN20M00107F1 | [1] | AIR CONDITIONER | SMAIR CONDITIONING Assy, Serial Range: YQ11-06001-YQ11-06070 Superseded by part number: YT20M00022F4 |
| 48. | YN20M00107S048 | [1] | ROD | SM(For F1, F2 ONLY) Superseded by part number: YN20M00107S091 |
| 49. | YN20M00107S049 | [1] | ROD | SM |
| . . | YN20M00107F2 | [1] | AIR CONDITIONER | SMAIR CONDITIONING Assy, Serial Range: YQ11-06071-YQ11-06356 Superseded by part number: YT20M00022F4 |
| 50. | YN20M00107S050 | [1] | ROD | SM |
| 51. | YN20M00107S051 | [1] | PLATE | SM |
| . . | YN20M00107F3 | [1] | AIR CONDITIONER | SMAIR CONDITIONING Assy, Start Serial: YQ11-06357 Superseded by part number: YT20M00022F4 |
| 54. | YN20M00107S054 | [1] | SCREW | SMCap |
| 60. | YN20M00107S060 | [1] | PACKING | KOB |
| 1. | YN20M00107S001 | [23] | SCREW | KOBTapping |
| 61. | YN20M00107S061 | [1] | PACKING | KOB |
| 2. | YN20M00107S002 | [1] | HARNESS | KOB Superseded by part number: YT20M00022S002 |
| 62. | YN20M00107S062 | [1] | PACKING | KOB |
| 3. | YN20M00107S003 | [3] | ACTUATOR | KOB Superseded by part number: YT20M00022S113 |
| 63. | YN20M00107S063 | [1] | O-RING | SMO-ring Superseded by part number: 2445Z1604D6 |
| 4. | YN20M00107S004 | [1] | RESISTOR | KOB Superseded by part number: LQ20M00059S039 |
| 77. | YN20M00107S077 | [1] | GASKET | SMPacking |
| 5. | YN20M00107S005 | [1] | CASE | KOB |
| 78. | YN20M00107S078 | [1] | RIGID TUBE | SM |
| 6. | YN20M00107S006 | [1] | DAMPER | KOB |
| 79. | YN20M00107S079 | [1] | RIGID TUBE | SM |
| 7. | YN20M00107S007 | [1] | LEVER | KOB |
| 82. | YN20M00107S082 | [1] | RIGID TUBE | SM |
| 8. | YN20M00107S008 | [1] | CASE | KOBCase (For F1 ONLY) |
| 83. | YN20M00107S083 | [1] | BRACKET | SM(For F2, F3 ONLY) |
| 9. | YN20M00107S009 | [1] | DAMPER | KOB |
| 84. | YN20M00107S084 | [1] | BOX | SMCase (For F2, F3 ONLY) |
| 10. | YN20M00107S010 | [1] | LEVER | KOB |
| 85. | YN20M00107S085 | [1] | SENSOR | SMThermometer (For F3 ONLY) |
| 11. | YN20M00107S011 | [1] | BLOWER | KOBMotor Superseded by part number: YN20M00107S111 |
| 86. | YN20M00107S086 | [1] | BOX | SMCase (For F3 ONLY) |
| 12. | YN20M00107S012 | [1] | LEVER | KOB |
| 87. | YN20M00107S087 | [1] | BOX | SMCase (For F3 ONLY) |
| 13. | YN20M00107S013 | [1] | DAMPER | KOB |
| 88. | YN20M00107S088 | [1] | LEVER | SM(For F3 ONLY) |
| 14. | YN20M00107S014 | [1] | LEVER | KOB |
| 89. | YN20M00107S089 | [1] | LEVER | SM(For F3 ONLY) |
| 15. | YN20M00107S015 | [1] | LEVER | KOB |
| 90. | YN20M00107S090 | [1] | LEVER | SM(For F3 ONLY) |
| 16. | YN20M00107S016 | [1] | ROD | KOB |
| 91. | YN20M00107S091 | [1] | ROD | SM(For F3 ONLY) |
| 17. | YN20M00107S017 | [1] | ROD | KOB |
| 92. | YN20M00107S092 | [1] | PLATE | SM(For F3 ONLY) |
| 18. | YN20M00107S018 | [1] | ROD | KOB |
| 19. | YN20M00107S019 | [2] | RELAY | SM |
| 20. | YN20M00107S020 | [1] | EVAPORATOR | KOB |
| 21. | YN20M00107S021 | [1] | VALVE | KOB |
| 22. | 2445Z1604D4 | [1] | O-RING | KOB |
| 23. | 2445Z1604D5 | [2] | O-RING | KOB |
| 24. | YN20M00107S024 | [2] | SCREW | SMCap |
| 25. | YN20M00107S025 | [1] | THERMOSTAT | KOB |
| 26. | YN20M00107S026 | [1] | HOLDER | KOBThermister |
| 27. | YN20M00107S027 | [1] | CORE | KOBHeater |
| 28. | YN20M00107S028 | [1] | HOLDER | KOBPipe |
| 29. | YN20M00107S029 | [1] | THERMOSTAT | KOB(For F1,F2 ONLY) Superseded by part number: YN20M00107S085 |
| 31. | YN20M00107S031 | [9] | SCREW | KOBTapping |
| 32. | YN20M00107S032 | [1] | CASE | SM(For F1, F2 ONLY) Superseded by part number: YN20M00107S086 |
| 33. | YN20M00107S033 | [1] | CASE | SM(For F1, F2 ONLY) Superseded by part number: YN20M00107S087 |
| 36. | YN20M00107S036 | [1] | GUARD | SMDamper |
| 37. | YN20M00107S037 | [1] | GUARD | SMDamper |
| 38. | YN20M00107S038 | [1] | GUARD | SMDamper |
| 39. | YN20M00107S039 | [1] | GASKET | SMPacking |
| 40. | YN20M00107S040 | [1] | GASKET | SMPacking |
| 41. | YN20M00107S041 | [1] | LEVER | SM |
| 42. | YN20M00107S042 | [1] | LEVER | SM |
| 43. | YN20M00107S043 | [1] | LEVER | SM |
| 44. | YN20M00107S044 | [1] | LEVER | SM(For F1, F2 ONLY) Superseded by part number: YN20M00107S088 |
| 45. | YN20M00107S045 | [1] | LEVER | SM |
| 46. | YN20M00107S046 | [1] | LEVER | SM(For F1, F2 ONLY) Superseded by part number: YN20M00107S089 |
