神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (300-01-1) - ELEC ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
698 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC03E00008F1 | [1] | upper | |
| 1. | YN24S00008F1 | [1] | RELAY | KOBAssy, Battery |
| 2. | LC53S00001D1 | [1] | HORN,420Hz | KOBHigh |
| 3. | LC53S00001D2 | [1] | HORN,350Hz | KOBLow |
| 5. | ZM73C08020 | [6] | BOLT,M8x20mm - Course Thread | KOBSems |
| 6. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBSems |
| 7. | LC03E01020P1 | [1] | BRACKET | KOB |
| 8. | ZW16P06000 | [2] | WASHER | KOB |
| 9. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 11. | YN03E01053P1 | [1] | COVER | KOB |
| 24. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBSems |
| 25. | 2427P1836D30 | [1] | WEATHERSTRIP | KOB |
