凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (02-014) - RADIATOR GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
187 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Condenser/Radiator
|
| 2. |
BN2396823
|
[1] |
HOSE
|
BN
Gates 26517 2 X 2-1/4
|
| 3. |
BN2393820
|
[1] |
HOSE
|
BN
Gates 26507 2" X 9.5
|
| 4. |
BN2393865
|
[1] |
HOSE,2.00" ID, 2.25" ID, SAE 20R4 CLASS D2
|
BN
Gates 20844
|
| 5. |
BN2393862
|
[1] |
HOSE,2.00" mm ID, SAE 20R4 CLASS D2
|
BN
Gates 21473
|
| 6. |
BN2390189
|
[2] |
ADAPTER
|
BN
Hose Mender 2"
|
| 8. |
BN51674
|
[2] |
HOSE CLAMP
|
BN
Adjustable #40
|
| 9. |
BN2296306
|
[6] |
CLAMP
|
BN
Hose H32 SS
|
| 10. |
BN2290646
|
[1] |
FITTING
|
BN
744440
|
| 11. |
BN76094
|
[2] |
HOSE CLAMP
|
BN
SS #M4 Superseded by part number: 87485000
|
| 12. |
BN2390873
|
[3] |
HOSE,0.31" ID
|
BN
Fuel, 815-25R
|
| 13. |
BN7146236
|
[1] |
RADIATOR
|
BN
Pad
|
| 14. |
BN2297363
|
[2] |
MOUNTING PLATE
|
BN
Isolator 200106R1
|
| 15. |
BN2303148
|
[2] |
Flat 5/8
|
|
| 16. |
87310322
|
[2] |
NUT
|
BN
Hex, 5/8-11, GB, DOR
|
| 17. |
BN1913319F
|
[12] |
HH 3/8-24 X 1 NF
|
|
| 18. |
BN2303412
|
[12] |
LOCK WASHER
|
BN
3/8 Superseded by part number: 80680
|
| 19. |
87529233
|
[12] |
WASHER,0.41" ID x 0.81" OD x 0.09" Thk
|
BN
3/8"
|
| 20. |
BN7146183
|
[1] |
SHROUD
|
BN
Fan UNI
|
| 21. |
BN2290512
|
[1] |
FITTING
|
BN
2503-16-16
|
| 22. |
BN2290576
|
[1] |
FITTING
|
BN
3503-16-16
|
| 23. |
BN2296336
|
[2] |
CLAMP
|
BN
Hose H8 SS
|
| 24. |
BN2293891
|
[2] |
HOSE,0.75" ID
|
BN
Heater 28418
|
| 25. |
BN2390194
|
[1] |
ADAPTER
|
BN
15-3684
|
| 26. |
BN310446
|
[2] |
HOSE CLAMP
|
BN
#12, Stainless Steel
|
| 27. |
BN2390875
|
[1] |
HEATER HOSE,1.00" ID
|
BN
Heater 28413
|
| 28. |
BN2390990
|
[1] |
3/8" Overflow (Rad)
|
|
| 30. |
BN7146189
|
[1] |
SUPPORT
|
BN
Fan Ring/CAT
|
