凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (02-013) - RADIATOR COWLING GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
295 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN1470404C
|
[20] |
LOCK NUT
|
BN
NC 3/8-16 Flex Lock Superseded by part number: 231-4146
|
| 2. |
BN1913319C
|
[20] |
BOLT
|
BN
HH 3/8-16 X 1 NC Superseded by part number: 413-616
|
| 3. |
87529233
|
[40] |
WASHER,0.41" ID x 0.81" OD x 0.09" Thk
|
BN
3/8"
|
| 4. |
BN7146471
|
[1] |
SHEET
|
BN
Cowling RH/CS 4 WH
|
| 5. |
BN7146472
|
[1] |
SHEET
|
BN
Cowling LH/RS 4 WH
|
| 6. |
BN7146473
|
[1] |
SHEET
|
BN
Cowling Top 4 WH
|
| 7. |
BN7146474
|
[1] |
SHEET
|
BN
Cowling Bottom 4 WH
|
| 8. |
BN7146475
|
[2] |
COWLING
|
BN
Side
|
| 9. |
BN7146476
|
[1] |
COWLING
|
BN
Top
|
