神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (320-01-1) - HARNESS ASSY, UPP (PLATE FLOOR) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
520 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC13E00032F1 | [1] | HARNESS | KOBAssy, Upper (Plate, Floor) |
| 1. | YN13E01449P3 | [1] | HARNESS | KOB |
| 2. | PY01P01043D3 | [35] | CABLE TIE,188mm L | KOB |
| 3. | YN13E01375P1 | [14] | CLIP,M8 x 8.20mm Shank | KOB |
| 4. | LC13E01186P1 | [1] | HARNESS | KOB |
| 5. | ZW26X08000 | [1] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 6. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 7. | PY01P01043D8 | [3] | CABLE TIE,102mm L | KOB |
| 9. | LE13E01005P1 | [1] | CABLE,100mm L | KOB |
| 10. | ZW16P08000 | [1] | WASHER | KOB |
