神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (350-01-1) - IDLER ASSY, CRAWLER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
221 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN52D00034F1 | [1] | IDLER | KOBAssy, Crawler Superseded by part number: YN52D00039F2 |
| 1. | YN52D00009F1 | [1] | IDLER | KOBAssy, See Page 356 Superseded by part number: LQ52D00044F1 |
| 2. | YN54D00013F1 | [1] | IDLER | KOBAdjust Assy, See Page 360 C, Serial Range: YQ11-06001-YQ11-06110 Superseded by part number: YN54D00015F2 |
| . . | YN54D00014F1 | [1] | ADJUSTER | KOBAdjust Assy, See Page 360, Start Serial: YQ11-06111 Superseded by part number: YN54D00015F2 |
| 3. | ZS13C16045 | [2] | SCREW | KOBScrew |
| 4. | 2444P803 | [1] | LUBE NIPPLE,5/8" - 18 x 64mm L, 19mm Hex | KOB |
