神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (367-01-1) - ROLLER ASSY, TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
889 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF64D00002F1 | [1] | TRACK ROLLER | KOBAssy Superseded by part number: LQ64D00025F1 |
| 1. | YF64D00001F1 | [16] | ROLLER | KOBTrack, Low Superseded by part number: LQ64D00054F1 |
| 1-1. | YN64D01021P1 | [1] | ROLLER | KOB |
| 1-2. | YN64D01041P1 | [2] | COLLAR | KOB |
| 1-3. | YN64D01042P1 | [1] | SHAFT | KOB Superseded by part number: LQ64D01028P1 |
| 1-4. | 2405P489 | [2] | BUSHING,66mm ID x 87mm OD x 64.5mm L | KOB |
| 1-5. | YN64D01043P1 | [2] | PIN | KOB |
| 1-6. | 2445R451F1 | [2] | SEAL,90mm ID x 114.45mm OD x 33mm Thk | KOBFloating Superseded by part number: 2445R441F1 |
| 1-7. | ZD11G06000 | [2] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOB |
| 1-8. | ZE82T04000 | [2] | PLUG | KOB |
| 2. | 2420P1580D4 | [64] | BOLT,Hex, M18 x 1.5 x 80mm | KOBCap |
