神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (374-01-1) - ROLLER ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
199 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN64D00032F1 | [1] | Upper | |
| 1. | YN64D01068F1 | [4] | ROLLER | KOBAssy Superseded by part number: YN64D01144F1 |
| 1-1. | 2413N469 | [1] | ROLLER | KOB |
| 1-2. | YN64D01069P1 | [1] | SHAFT | KOB Superseded by part number: YN64D01144F1 |
| 1-3. | 2418P21176 | [1] | COLLAR | KOB Superseded by part number: 2418P22958 |
| 1-4. | YN64D01038P1 | [1] | PLATE | KOB |
| 1-5. | YN64D01026P1 | [1] | COVER | KOB |
| 1-6. | 2405T852 | [1] | BUSHING,45mm ID x 50mm OD x 50mm L | KOB |
| 1-7. | 2445R361F1 | [1] | SEAL,48mm ID x 68.6mm OD x 27mm Thk | KOBFloating |
| 1-8. | ZD11P06500 | [1] | O-RING | KOB |
| 1-9. | YN64D01016P1 | [2] | BOLT | KOB |
| 1-10. | ZE82T04000 | [1] | PLUG | KOB |
| 1-11. | ZR26X07500 | [1] | RING | KOBSnap |
| 2. | YN52F01100D3 | [4] | CAP | KOBScrew |
| 3. | ZN13C20016 | [4] | NUT | KOB |
| 4. | ZW13H20000 | [4] | WASHER | KOB |
