神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (380-01-1) - SHOE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
401 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN60D00060F2 | [1] | | |
| . . | YN60D00060F4 | [1] | | |
| . . | YN60D00060F5 | [1] | | |
| . . | YN60D00060F6 | [1] | | |
| . . | YN60D00060F8 | [1] | | |
| . . | YN60D00060F9 | [1] | | |
| . . | YN60D00054F2 | [2] | SHOE | KOBAssy |
| 1. | YN62D00017F1 | [1] | CHAIN | KOBTrack Link Assy |
| 1-1. | 2424J170D1 | [46] | TRACK LINK | KOB(RH) |
| 1-2. | 2424J170D2 | [46] | LINK | KOBTrack (LH) |
| 1-3. | 2405P694 | [45] | BUSHING,37.13mm ID x 58.78mm OD x 138mm L | KOBTrack |
| 1-4. | 2419P3042 | [45] | PIN,36.63mm OD x 210mm L | KOBTrack |
| 1-5. | 2405P392 | [1] | BUSHING,36.83mm ID x 58.78mm OD x 129mm L | KOBMaster |
| 1-6. | YN62D01017P1 | [1] | PIN,36.5mm OD x 210mm L | KOBMaster |
| 1-7. | 2418T25964 | [2] | COLLAR | KOB |
| 1-8. | YN62D01028P1 | [90] | SEAL,37.25mm ID x 60.5mm OD x 14.2mm Thk | KOB |
| 3. | YN60D00017P1 | [46] | SHOE | KOB(600mm) Superseded by part number: 2424N196D1 |
| 12. | 2420Z1292 | [184] | BOLT | KOBShoe Superseded by part number: |
| 15. | 2420Z1293 | [184] | NUT | KOB Superseded by part number: 2420P1584 |
| . . | YN60D00054F4 | [2] | Consists Of Ref. 1, 5, 12 & 15 | |
| 5. | 2424N196D1 | [46] | SHOE,600mm Triple Grouser | KOB(h. D) (600mm) (600mm) |
| . . | YN60D00054F5 | [2] | SHOE | KOBAssy Consists Of Ref. 1, 6, 12 & 15 |
| 6. | 2424N196D2 | [46] | SHOE,700mm Triple Grouser | KOB(700mm) |
| . . | YN60D00054F6 | [2] | Consists Of Ref. 1, 7, 12 & 15 | |
| 7. | 2424N196D3 | [46] | SHOE,800mm Triple Grouser | KOB(800mm) |
| . . | YN60D00054F8 | [2] | Consists Of Ref. 1, 9, 13 & 15 | |
| 9. | YN60D00057P1 | [46] | TRACK SHOE | KOBFlat (600mm) |
| 13. | 2420T7262D2 | [184] | SCREW | KOBBolt, Shoe |
| . . | YN60D00054F9 | [2] | Consists Of Ref. 1, 10, 14 & 15 | |
| 10. | 2424N205 | [46] | SHOE | KOBTriangle (900mm) |
| 14. | 2420T7262D1 | [184] | BOLT | KOBShoe |
