凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (04-011) - FRONT FENDER GROUP - ROAD SIDE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
634 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN7141968
|
[1] |
STEP
|
BN
Front Step
|
| 2. |
BN7141969
|
[1] |
SPLASH SHIELD
|
TYR
Front Splash PL R/S
|
| 3. |
BN303550
|
[1] |
SUPPORT
|
TYR
Walkway Support R/S
|
| 4. |
BN301788
|
[1] |
SUPPORT
|
BN
Walkway, Middle LH
|
| 5. |
BN7143130
|
[1] |
COVER ASSY
|
BN
Head LT Mud Cover
|
| 6. |
BN313053
|
[1] |
FENDER
|
BN
Front, RS, Black
|
| 7. |
BN7141905
|
[1] |
SPLASH SHIELD
|
TYR
Rear Splash Platform
|
| 8. |
BN7141829
|
[1] |
PLATE
|
BN
Support Rod
|
| 9. |
BN7141893A
|
[1] |
Walkway R/S
|
|
| 10. |
BN7141860
|
[1] |
HOSE
|
BN
Door/Window Bumper
|
| 11. |
BN2401312
|
[8.25] |
MAT
|
BN
P-80 GRS/PSA
|
| 12. |
BN7141993
|
[1] |
ANGLE
|
BN
Step Plate
|
| 13. |
BN302280
|
[1] |
SPLASH SHIELD
|
BN
Splash, LH Rear
|
| 14. |
9515003
|
[12] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9
|
BHB
|
| 15. |
BN300472
|
[20] |
BOLT
|
BN
M10-1.5 X 35, HH, SS
|
| 16. |
9706687
|
[1] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 17. |
626-12035
|
[10] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd
|
CAS
|
| 18. |
BN300507
|
[32] |
WASHER
|
BN
M10, Flat, SS
|
| 19. |
BN300500
|
[11] |
WASHER,M12, 10.9
|
BN
Superseded by part number: 86625255
|
| 20. |
100037
|
[32] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
BN304551
|
[9] |
SCREW
|
BN
M12-1.75, FLN, 10.9 Superseded by part number: 832-46412
|
| 22. |
BN2403271
|
[4] |
BOLT
|
BN
Carriage SS
|
| 23. |
BN50140
|
[4] |
LOCK WASHER
|
BN
Spring, 1/4", SS
|
| 24. |
BN50138
|
[4] |
WASHER,1/4", SS
|
BN
|
| 25. |
BN50054
|
[4] |
NUT,1/4"-20, SS
|
A
|
| 26. |
BN2394894
|
[4] |
RIVET
|
BN
Pop 97525A032 3/16X
|
