神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (155-01-1) - CONTROL LINES, PUMP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
906 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZX22M12048 | [1] | HOSE | KOB(87573116) |
| 2. | 2420R537D052 | [1] | HOSE,9.60mm ID x 520mm L | KOB(87532888) Superseded by part number: 2420R537D055 |
| 3. | ZX23M06048 | [1] | HOSE | KOB Superseded by part number: ZX23M06050 |
| 4. | YN06H01052D1 | [1] | HOSE | KOB |
| 5. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMFilter, Inline, (87338500) |
| 6. | YN06H01044P1 | [1] | TEE | KOB(87532893) |
| 7. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB(72285615, 72217409) |
| 8. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(72214717) |
| 9. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(72214523) |
| 10. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, (72214734) |
| 11. | 2444Z2345 | [1] | 90 ELBOW | KOB(87532891) |
| 12. | HH35X04004G3 | [1] | 90 ELBOW | KOBConnector, (72214735) |
