凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (10-007) - REAR FENDER, 66” Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
565 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
BN306321
|
[1] |
Fender, 66"
|
|
| 1. |
BN302346
|
[2] |
SPACER
|
BN
66 Fender, Front
|
| 2. |
100038
|
[16] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 3. |
BN302755
|
[8] |
BOLT
|
BN
M12-1.75 X 120, HH, 10.9 Superseded by part number: 309308
|
| 4. |
BN302747
|
[8] |
BOLT
|
BN
M12-1.75 X 50, HH, 10.9
|
| 5. |
BN8205181
|
[2] |
FENDER
|
BN
Rear Titan Superseded by part number: 86986012
|
| 6. |
BN8205209
|
[2] |
MOUNTING PLATE
|
BN
Rear Fender
|
| 6A. |
BN8194088
|
[1] |
MUDFLAP
|
BN
|
| 7. |
BN8091049
|
[2] |
SHEET METAL
|
TYR
Mud Flap Brace
|
| 8. |
BN8091048
|
[2] |
MOUNTING PLATE
|
BN
Mud Flap Superseded by part number: BN320352
|
| 9. |
BN310599
|
[2] |
MUDFLAP
|
BN
66"
|
| 10. |
BN2403263
|
[14] |
HH 3/8-16 X 1 1/2 SS
|
|
| 11. |
BN2294495
|
[14] |
LOCK NUT
|
BN
3/8-16 SS Flex Lock
|
