凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (10-008) - REAR FENDER, 73” Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
587 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
BN302313
|
[1] |
Rear, 73" Steel Complete
|
|
| 1. |
BN306032
|
[1] |
MOUNTING PLATE
|
BN
Rear Fender, CS
|
| 2. |
BN300491
|
[32] |
BOLT
|
BN
M12, FW, G5 Superseded by part number: 896-11012
|
| 3. |
BN301068
|
[16] |
NUT
|
BN
M12-1.75 X 25, HH, 10.9
|
| 4. |
BN304551
|
[16] |
SCREW
|
BN
M12-1.75, FLN, 10.9 Superseded by part number: 832-46412
|
| 5. |
BN306094
|
[1] |
FENDER
|
BN
CS
|
| 6. |
BN306093
|
[1] |
FENDER
|
BN
RS
|
| 7. |
BN306157
|
[1] |
MOUNTING PLATE
|
BN
Rear Fender, RS
|
| 7A. |
BN306263
|
[1] |
MUDFLAP
|
BN
73" Rear Complete
|
| 8. |
BN8091049
|
[2] |
SHEET METAL
|
TYR
Mud Flap Brace
|
| 9. |
BN306239
|
[2] |
MOUNTING PLATE
|
BN
Mud Flap
|
| 10. |
BN306236
|
[2] |
Mud 73" Tire
|
|
| 11. |
BN300472
|
[14] |
BOLT
|
BN
M10-1.5 X 35, HH, SS
|
| 12. |
BN300507
|
[28] |
WASHER
|
BN
M10, Flat, SS
|
| 13. |
100037
|
[14] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
