神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (572-01-1) - LIGHT ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
959 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YW80S00001F1 | [1] | LIGHT ASSY. | KOB Superseded by part number: 2456R442F1 |
| 1. | YW80S00001S001 | [1] | LAMP | KOBUnit |
| 2. | YW80S00001S002 | [1] | CAPPING | KOBRim |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 4. | YW80S00001S004 | [1] | GASKET | KOB |
| 5. | YW80S00001S005 | [1] | BULB | KOBValve |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONSpring |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONMachine Screw |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONSpacer |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONWasher |
| 10. | YW80S00001S010 | [1] | LOCK WASHER | KOB |
| 11. | YW80S00001S011 | [1] | NUT | KOB |
| 12. | YW80S00001S012 | [4] | SCREW | KOBCap Superseded by part number: ZS32T05025 |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONHarness |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONHarness |
