神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (730-01-1) - CONTROL LINES, MAIN (LONG RANGE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
799 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN06H00103F1 | [1] | Main | |
| . . | YN06H00102F1 | [1] | Main | |
| 1. | 2420R537D030 | [1] | HOSE,9.53mm ID x 300mm L | KOB |
| 2. | 2420R349D028 | [1] | HOSE,280.00 mm | KOB Superseded by part number: 2420R349D030 |
| 3. | 2420R349D055 | [1] | HOSE,6.35mm ID x 550mm L | KOB |
| 4. | 2420R537D088 | [1] | HOSE,9.60mm ID x 880mm L | KOB Superseded by part number: HX21E06088DX |
| 5. | 2420R349D125 | [1] | HOSE,1250.00 mm | KOB Superseded by part number: HX21E04125DX |
| 6. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| 7. | YN21V00005F1 | [1] | CHECK VALVE | KOBAssy, Check |
| 8. | YX52S00013P1 | [1] | SENSOR | SMPress (l. P.) Superseded by part number: LC52S00019P1 |
| 8-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 9. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 10. | ZH22X04006 | [2] | HYD CONNECTOR | KOB |
| 11. | ZH22X06000 | [7] | HYD CONNECTOR | KOB |
| 12. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| 13. | ZH32X04006 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| 14. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 15. | YN21V00005F3 | [1] | CHECK VALVE | KOBAssy, Check |
| 16. | 2444Z3711 | [2] | HYD CONNECTOR | KOB |
| 17. | 2444Z2336 | [2] | TEE | KOBTee |
| 18. | HH55Q06006G1 | [1] | TEE | KOB |
| 19. | 2444Z3421 | [1] | TEE | KOB |
| 20. | 2444T3402 | [1] | TEE | KOBTee Superseded by part number: HH55V06006G3 |
| 21. | YN06H01045P1 | [1] | 45 ELBOW | SM |
| 22. | ZH42X06000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 23. | 2444Z2891 | [1] | HYD CONNECTOR | KOB |
