神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (728-01-1) - CONTROLS, OPERATORS (LONG RANGE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
619 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00178F1 | [1] | Controls, Operators | |
| . . | YN03M00137F1 | [1] | (See Fig No. 120-01-1) | |
| . . | YN03M00138F1 | [1] | CONTROL | KOBControl Box Assy (See Fig No. 125-01-1) |
| . . | YN50E00018F1 | [1] | Instal (See Fig No. 129-01-1) | |
| . . | YN50M00013F1 | [1] | CONTROL LEVER | KOBPropel (See Fig No. 138-01-1) |
| . . | YN55M00003F1 | [1] | FLOOR MAT | KOBPedal Assy (See Fig No. 138-01-1) Superseded by part number: YN26M00064P1 |
| . . | YN54E00006F1 | [1] | Instal (See Fig No. 129-01-1) | |
| . . | YN12P01163F1 | [1] | CLAMP | KOB(See Fig No. 132-01-1) |
| . . | YN25M01180F1 | [1] | ARMREST | KOBRest (See Fig No. 132) |
| . . | YN03M01974F1 | [1] | | |
| 1. | YN03M02021F3 | [1] | GRIP | KOB, Serial Range: YQ11-06001-YQ11-06356 |
| 1-1. | YN03M01864P1 | [1] | LEVER | KOB |
| 1-2. | ZS31C04016 | [1] | SCREW,Phillips Drive, Pan HD, M4 x 16mm | KOBMachine |
| 1-4. | YN03M01866P1 | [1] | CASE | KOB |
| 1-5. | YN03M01972P1 | [1] | GRIP | KOB |
| 1-2. | YN03M02019P1 | [1] | SCREW | KOBCap |
| 1-6. | YN03M01864P1 | [1] | LEVER | KOB |
| 1-8. | YN03M01972P1 | [1] | GRIP | KOB |
| 2. | YN03M01862F1 | [1] | HANDLE GRIP | SM, Serial Range: YQ11-06001-YQ11-06356 Superseded by part number: YN03M02687F1 |
| 2-1. | YN03M01865P1 | [1] | LEVER | KOB |
| 2-2. | ZS31C04016 | [1] | SCREW,Phillips Drive, Pan HD, M4 x 16mm | KOBMachine |
| 2-3. | YN50E00017P1 | [1] | SWITCH ASSY | KOBAssy |
| 2-4. | YN03M01866P1 | [1] | CASE | KOB |
| 2-5. | YN03M01867P1 | [1] | GRIP | KOB Superseded by part number: YN03M02618P1 |
| 2. | YN03M02021F1 | [1] | HANDLE GRIP | SM, Start Serial: YQ11-06357 Superseded by part number: YN03M02687F1 |
| 2-2. | YN03M02019P1 | [1] | SCREW | KOBCap |
| 3. | YN03M01498P1 | [2] | BELLOWS | SMBoot |
| 4. | YN03M01328P2 | [2] | PLATE | KOB |
| 5. | ZN18C14011 | [2] | NUT | KOB |
