神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (736-01-1) - SUN VISOR ASSY (FRONT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
705 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN55C00013F1 | [1] | SUN VISOR | SMAssy |
| 1. | YN02C03645P1 | [1] | BRACKET | SMAssy |
| 1-4. | YN02C02285P1 | [2] | BAR | KOBFlat |
| 1-6. | ZS13C08020 | [4] | SCREW | KOB Superseded by part number: ZS18C08020 |
| 2. | YN55C01021F1 | [1] | GUARD | SMCover Assy |
| 2-1. | YN55C01019P1 | [1] | | |
| 2-2. | YN55C01020P1 | [1] | CHANNEL | KOB |
| 3. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBSems |
| 4. | ZM73C10030 | [2] | BOLT,M10x30mm - Course Thread | KOBSems |
| 5. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 6. | ZW16P08000 | [8] | WASHER | KOB |
| 7. | PH21C01136DL | [1] | GASKET,1380mm L | SMStrip, Weather |
| 8. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBCap |
| 9. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 10. | ZW16H10000 | [2] | WASHER | KOB |
