神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (813-01-1) - HARNESS ASSY, CAB (STD KEY 5 EQUIVALENT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
492 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03E00018F1 | [1] | Upper | |
| 1. | YN50S00026F3 | [1] | SWITCH ASSY | KOBSwitch Key |
| 2. | YN03E00020F1 | [1] | WIRE HARNESS | KOBUpper |
| 2-1. | YN54S00025P2 | [1] | CLUTCH | KOBAmplifier |
| 2-2. | YN01E01005P1 | [1] | IGNITION KEY | KOB |
| 2-3. | YN54S00009P1 | [1] | ANTENNA | KOB |
| 2-4. | YN54S01001P1 | [1] | STAY | KOB |
| 2-5. | YN17M01312P1 | [1] | DATA PLAQUE | SMLabel |
| 2-6. | ZS31C03006 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 6mm | KOBMachine |
| 2-7. | ZM66C06020 | [1] | BOLT | KOBSems |
| 2-8. | YN03E01059P1 | [1] | WIRE HARNESS | KOB |
| 2-9. | PY01P01043D3 | [22] | CABLE TIE,188mm L | KOB |
