神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (840-86-1) - BOOM GROUP, 5. 65M (AUTO GREASTER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
838 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02B00377F1 | [1] | Boom Group, 5.65m | |
| 1. | ZX25M06575 | [1] | HOSE | KOBHose |
| 2. | 2420R349D084 | [1] | HYDRAULIC HOSE,6.35 mm ID x 840.00 mm, SAE 100R7 | KOB Superseded by part number: 2420R349D085 |
| 3. | 2420R349D086 | [1] | HOSE | KOB Superseded by part number: HX21E04086DX |
| 4. | 2420R349D255 | [1] | HOSE | KOB Superseded by part number: HX21E04255DX |
| 5. | 2420R349D260 | [1] | HOSE | KOB Superseded by part number: HX21E04260DX |
| 6. | 2420R349D305 | [1] | HOSE ASSY. | KOB Superseded by part number: HX21E04240DX |
| 7. | 2479P2281D5 | [1] | DISTRIBUTOR | KOBAssy |
| 7-1. | 2479P2281S1 | [5] | ELEMENT | KOB |
| 7-6. | 2479P2281S6 | [1] | BOLT | KOB |
| 7-7. | 2479P2281S7 | [5] | CAP | KOB |
| 7-8. | ZD12P01090 | [6] | O-RING | KOB |
| 8. | YN02B01629P1 | [1] | BRACKET | KOB |
| 9. | YN02B01170P1 | [1] | PLATE | KOB |
| 10. | ZE82T06000 | [1] | PLUG | KOB |
| 11. | ZH22F06000 | [1] | CONNECTION | KOBConnector |
| 12. | ZG22E06000 | [1] | HYD CONNECTOR | KOB |
| 13. | 2444Z2002 | [5] | HYD CONNECTOR | KOB |
| 14. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 15. | ZH32Z06000 | [2] | ELBOW | KOB |
| 16. | ZG52U06000 | [1] | TEE | KOB |
| 17. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 18. | YN02B01200P1 | [5] | LUBE NIPPLE | KOB |
| 19. | ZS18C08050 | [2] | SCREW,Hex, M8 x 50mm | KOBCap |
| 20. | ZS18C14040 | [2] | SCREW,Hex, M14 x 40mm | KOBCap |
| 21. | ZW16H14000 | [2] | WASHER | KOB |
| 22. | ZW16H08000 | [2] | WASHER | KOB |
| 23. | PY01P01043D3 | [13] | CABLE TIE,188mm L | KOB |
