凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (02-009) - BATTERY GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
242 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN300069
|
[1] |
BOX
|
BN
Battery
|
| 2. |
BN301793
|
[1] |
LID
|
BN
Battery Box
|
| 3. |
9515003
|
[10] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9
|
BHB
|
| 4. |
BN300499
|
[20] |
WASHER,M10, 10.9
|
BN
Superseded by part number: 896-11010
|
| 5. |
BN304419
|
[10] |
NUT
|
BN
M10-1.5, NLN, 10.9 Superseded by part number: 100037
|
| 6. |
BN2290753
|
[2] |
GROMMET
|
BN
2870 (7/8" Hole)
|
| 7. |
BN50061
|
[4] |
LOCK NUT
|
BN
3/8"-16, G5, UNC, Whiz Superseded by part number: 231-4146
|
| 8. |
BN320331
|
[2] |
BRACKET
|
CUR
Mount, Battery
|
| 9. |
BN55360
|
[4] |
LOCK NUT
|
BN
5/16"-18, NLN, G5 Superseded by part number: 280736
|
| 10. |
BN50141
|
[4] |
WASHER
|
BN
5/16, FW, G5 Superseded by part number: 80664
|
| 11. |
BN300091
|
[2] |
BATTERY
|
BN
12V DC, 950 CCA
|
| 12. |
BN2390287
|
[4] |
BOLT
|
BN
battery 390-005
|
| 13. |
BN302201
|
[2] |
Battery, Neoprene
|
|
