凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (06-002) - HYDRAULIC TANK GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
585 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN300394
|
[8] |
BOLT
|
BN
Hex, M14 x 60, 8.8, Full Thd
|
| 2. |
BN301011
|
[4] |
NUT
|
BN
M6-1 X 12, HH, 10.9
|
| 3. |
BN301316
|
[2] |
M8-1.25 X 90, HH, 10.9
|
|
| 4. |
BN302877
|
[1] |
MANIFOLD
|
BN
Oil Return
|
| 5. |
BN302898
|
[2] |
FITTING
|
BN
24Mor-24Mb
|
| 6. |
BN306733
|
[1] |
GASKET
|
BN
Cover Plate
|
| 7. |
BN306736
|
[1] |
SWITCH
|
BN
Level, Float
|
| 8. |
BN306734
|
[1] |
COVER
|
BN
Cleanout
|
| 9. |
87270936
|
[1] |
FILTER
|
BN
Intank, SAE 24, 6ABS
|
| 10. |
BN303906
|
[1] |
SHIELD
|
BN
Heat
|
| 11. |
BN304242
|
[1] |
TANK
|
BN
HYD. Oil Superseded by part number: 87267084
|
| 12. |
BN304315
|
[2] |
NUT
|
BN
M8-1.25, FLN, 10.9 Superseded by part number: 832-46408
|
| 13. |
BN304339
|
[1] |
VALVE
|
BN
Press Valve
|
| 14. |
BN305020
|
[1] |
SENDER UNIT
|
BN
Temperature, 3/8 NPT
|
| 15. |
9841223
|
[1] |
PLUG,1-1/16" - 12 ORB
|
BEL
|
| 16. |
BN50061
|
[8] |
LOCK NUT
|
BN
3/8"-16, UNC, Whiz Superseded by part number: 231-4146
|
| 17. |
BN53957
|
[1] |
GAUGE
|
BN
Sight With Temperature
|
| 18. |
86639038
|
[4] |
BOLT,Hex, M6 x 1 x 25mm, Cl 10.9, Full Thd
|
FAR
|
| 19. |
BN300488
|
[8] |
WASHER
|
BN
M6, Flat, 8.8 Superseded by part number: 87529302
|
| 20. |
86624185
|
[2] |
WASHER,8.8mm ID x 17.5mm OD x 2mm Thk
|
FOR
|
| 21. |
BN306337
|
[1] |
BRACKET
|
BN
Oil Manifold
|
