神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (861-86-1) - ARM GROUP, 2.94M (9FT 8IN) (AUTO GREASTER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
635 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN12B00833F1 | [1] | Group | |
| . . | YN12B00655F1 | [1] | Group (See Fig No.580-01-1,2) | |
| . . | YN12B00835F1 | [1] | Group (hd) | |
| . . | YN12B00760F1 | [1] | Group (See Fig No.580-02-1,2) | |
| . . | YN12B00884F1 | [1] | Group (Nibbler & Breaker) | |
| . . | YN12B00880F1 | [1] | Group (See Fig No.580-60) | |
| . . | YN12B00673F1 | [1] | Group | |
| 1. | ZX35M06165 | [1] | HOSE | KOB |
| 2. | 2420R349D086 | [1] | HOSE | KOB Superseded by part number: HX21E04086DX |
| 3. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB Superseded by part number: HX21E04110DX |
| 4. | 2420R349D135 | [1] | HOSE,6.35mm ID x 1350mm L | KOB |
| 5. | 2479P2281D3 | [1] | DISTRIBUTOR | KOBAssy |
| 5-1. | 2479P2281S1 | [3] | ELEMENT | KOB |
| 5-4. | 2479P2281S4 | [1] | BOLT | KOBAssy |
| 5-7. | 2479P2281S7 | [3] | CAP | KOB |
| 5-8. | ZD12P01090 | [4] | O-RING | KOB |
| 6. | LC12B01521P1 | [1] | COVER | KOB |
| 7. | ZH22Z06000 | [1] | CONNECTION | KOB |
| 8. | 2444Z2002 | [4] | HYD CONNECTOR | KOB |
| 9. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 10. | ZH42Z04000 | [1] | ELBOW | KOB |
| 11. | 2444T4678 | [3] | LUBE NIPPLE | KOB |
| 12. | ZE82T06000 | [1] | PLUG | KOB |
| 13. | LC12B01523P1 | [1] | PLATE | KOB |
| 14. | ZC46X10009 | [3] | CLIP,10.1mm | KOB |
| 15. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBSems |
| 16. | ZS18C08050 | [2] | SCREW,Hex, M8 x 50mm | KOBCap |
| 17. | ZS18C08080 | [4] | SCREW,Hex, M8 x 80mm | KOBCap |
| 18. | ZN18C06005 | [3] | NUT | KOB |
| 19. | ZW26X06000 | [3] | LOCK WASHER | KOB |
| 20. | ZW16H08000 | [6] | WASHER | KOB |
| 21. | ZW16P06000 | [3] | WASHER | KOB |
| 22. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOB |
| 23. | 2418R676D4 | [1] | TUBE | KOB |
| 24. | 2418R676D11 | [1] | TUBE | KOB |
| 25. | 2418R676D13 | [1] | HYD TUBE | KOB |
