现代零件查询R210LC-7H(#9001-) CYLINDER HEADEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
294 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
22100-93C00
|
[1] |
HEAD ASSY-CYLINDER
|
|
| N1. |
22111-93001
|
[1] |
HEAD-CYLINDER
|
|
| 2. |
22112-93100
|
[6] |
INSERT-VLV SEAT INLET
|
|
| 3. |
22113-93C00
|
[6] |
INSERT-VLV SEAT EXHAUST
|
|
| 4. |
22114-93000
|
[6] |
VALVE GUIDE,INLET
|
|
| 5. |
22115-93000
|
[6] |
VALVE GUIDE,EXHAUST
|
|
| 6. |
15733-25000
|
[18] |
CAP-SEALING
|
|
| 7. |
15733-22000
|
[5] |
CAP-SEALING
|
|
| N8. |
22151-93000
|
[1] |
STUD
|
|
| 9. |
22152-93002
|
[12] |
STUD
|
|
| 10. |
22138-93000
|
[6] |
TUBE-NOZZLE
|
|
| 11. |
22134-72000
|
[6] |
O-RING
|
|
| 14. |
22321-93000
|
[20] |
BOLT
|
|
| 15. |
22331-93000
|
[6] |
BOLT
|
|
| 16. |
11961-10321
|
[6] |
BOLT
|
|
| 17. |
22311-93020
|
[1] |
GASKET
|
|
