现代零件查询R210LC-7H(#9001-) VALVE GEAR TRAINEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
973 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
22211-93000
|
[6] |
VALVE-INLET
|
|
| 2. |
22212-93000
|
[6] |
VALVE-EXHAUST
|
|
| 3. |
22221-93000
|
[12] |
SPRING-VALVE OUTLET
|
|
| 4. |
22230-93000
|
[12] |
SPRING
|
|
| 5. |
22224-93010
|
[12] |
SEAL-VALVE STEM
|
|
| 6. |
22222-93000
|
[12] |
RETAINER-VALVE SPRING
|
|
| 7. |
22223-93001
|
[24] |
LOCK-V/SPRING RETAINER
|
|
| 8. |
22225-93000
|
[12] |
RETAINER-LOWER
|
|
| 9. |
22226-45000
|
[12] |
CAP-VALVE
|
|
| . |
24500-93000
|
[1] |
ROCKER SHAFT TOTAL ASSY
|
|
| -1. |
24510-93100
|
[12] |
ROCKER ASSY
|
|
| N10. |
24527-93000
|
[1] |
ROCKER
|
|
| 11. |
24513-93000
|
[1] |
BUSHING-ROCKER
|
|
| 12. |
24532-83010
|
[1] |
SCREW-ADJUSTING
|
|
| 13. |
13104-10001
|
[1] |
NUT
|
|
| -2. |
24530-93000
|
[1] |
ROCKER SHAFT ASSY
|
|
| 14. |
24511-93000
|
[1] |
SHAFT-ROCKER
|
|
| N15. |
15731-15181
|
[2] |
PLUG-EXPANSION
|
|
| 16. |
24516-93000
|
[5] |
BRACKET-ROCKER SHAFT
|
|
| 17. |
24515-93010
|
[1] |
BRACKET-ROCKER SHAFT
|
|
| 18. |
22232-93000
|
[1] |
SCREW-SET
|
|
| 19. |
24541-93000
|
[5] |
SPRING-ROCKER
|
|
| 20. |
24512-72000
|
[2] |
WASHER
|
|
| 21. |
24514-72000
|
[2] |
RING-SNAP
|
|
| 22. |
22234-93000
|
[1] |
PLUG
|
|
| 23. |
22231-93000
|
[6] |
BOLT
|
|
| 23. |
13510-10001
|
[6] |
WASHER-PLAIN
|
|
| 24. |
24135-93000
|
[12] |
BOLT-TAPPET
|
|
| 25. |
24131-93001
|
[12] |
ROD-PUSH
|
|
| 26. |
24110-93000
|
[1] |
SHAFT-CAM
|
|
| 27. |
24121-93000
|
[1] |
PLATE-THRUST
|
|
| 28. |
11403-08161
|
[2] |
BOLT-FLANGE
|
|
| 29. |
14530-05190
|
[1] |
KEY-WOODRUFF
|
|
