| . . | YN12B00439F4 | [1] | Group | |
| A2. | YY12B01074P1 | [1] | LINK | KOB |
| A3. | YW12B01034P1 | [1] | LINK | KOB |
| A4. | YN12B01719P1 | [2] | PIN,68mm OD x 470mm L | KOB |
| A5. | YN12B01720P1 | [1] | PIN | KOB |
| A6. | YN12B01721P1 | [1] | PIN | KOB Superseded by part number: YN12B01720P1 |
| A7. | 2444R1117D150 | [1] | HOSE,6.4mm ID x 1500mm L | KOB |
| A8. | 2444R1117D180 | [1] | HOSE,6.4mm ID x 1800mm L | KOB |
| A9. | 2444R1117D195 | [1] | HOSE,6.40mm ID x 1950mm L | KOB Superseded by part number: HX21E04195DY |
| A10. | YN12B01157P1 | [1] | BRACKET | KOB |
| A11. | ZH32Z04002 | [2] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| A12. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A13. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| A14. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust Superseded by part number: 84499663 |
| A16. | 2445R220D6 | [2] | SEAL,90mm ID x 105mm OD x 6mm Thk | KOBDust |
| A17. | YN12B01610D1 | [6] | SHIM | KOB(2.0) |
| A18. | B16T0442D56 | [6] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOB(0.5) |
| A19. | B16T0442D43 | [6] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOB(0.9) |
| A20. | B16T0442D19 | [6] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOB(0.6) |
| A21. | YN12B01153P1 | [2] | SHIM | KOB(6.0) |
| A22. | YN12B01152P1 | [2] | SHIM | KOB(9.0) |
| A23. | ZC48X10009 | [2] | CLIP,10mm ID, 9mm Bolt Hole, P Type | KOB |
| A24. | ZC46X10009 | [3] | CLIP,10.1mm | KOB |
| A25. | HS18C14115G2 | [2] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBCap |
| A26. | ZS18C14055 | [6] | BOLT,Hex, M14 x 55mm | KOBCapscrew |
| A27. | ZN18C14011 | [4] | NUT | KOB |
| A28. | ZN18C06005 | [5] | NUT | KOB |
| A29. | ZW26X06000 | [5] | LOCK WASHER | KOB |
| A30. | ZW16X14000 | [6] | WASHER | KOB |
| A31. | ZW16X06000 | [5] | WASHER | KOB Superseded by part number: 86588450 |
| A37. | YN12B01971F1 | [1] | LINK | KOBAssy, Bucket |
| A37-1. | NSS | [1] | NOT SOLD SEPARAT | CONLink, Bucket |
| A37-2. | YN12B01836P1 | [2] | BUSHING,65.28mm ID x 80mm OD x 61mm L | KOB |
| A37-3. | YN12B01970P1 | [2] | BUSHING,60.2mm ID x 75mm OD x 62mm L | KOB |
| A38. | 2445R220D1 | [6] | SEAL,60mm ID x 75mm OD x 5mm Thk | KOBDust |
| . . | YN12B00589F1 | [1] | ARM | KOBAssy |
| B1. | NSS | [1] | NOT SOLD SEPARAT | CONArm |
| B1-29. | 2418T24122 | [1] | PLATE | KOB |
| B1-30. | YN12B01105P1 | [1] | PLATE | KOB |
| B1-39. | 2416T9804 | [6] | BLOCK | KOBTapped |
| B1-40. | YN12B01102P1 | [2] | BLOCK | KOBTapped |
| B2. | YN12B01836P1 | [2] | BUSHING,65.28mm ID x 80mm OD x 61mm L | KOB |
| B3. | YN12B01970P1 | [2] | BUSHING,60.2mm ID x 75mm OD x 62mm L | KOB |
| B4. | YN12B01597P1 | [2] | BUSHING | KOBID 90 x OD 105 x 89mm Long Superseded by part number: LQ12B01368P1 |
| . . | YN12B00435F1 | [1] | ARM | KOBInstal |
| C1. | YN12B01722P1 | [1] | PIN,90mm OD x 580mm L | KOB |
| C2. | YN12B01715P1 | [1] | PIN,85mm OD x 280mm L | KOB |
| C3. | HS18C16150G2 | [1] | SCREW | KOBCap |
| C4. | ZN18C16013 | [2] | NUT | KOB |
| C5. | 2420Z1047 | [1] | SLOTTED NUT | KOB |
| C6. | ZP15D08100 | [1] | SPRING | KOBSplit |
| C7. | 2418Z715 | [1] | WASHER | KOB |
| C8. | B16T0442D53 | [1] | SHIM,92mm ID x 160mm OD x 0.5mm Thk | KOB(0. 5) |
| C9. | B16T0442D40 | [1] | SHIM,92mm ID x 160mm OD x 0.9mm Thk | KOB(0. 9) |
| C10. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOB(0. 5) |
| C11. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOB(0. 9) |
| C12. | B16T0442D62 | [1] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOB(1. 6) |
| C13. | YN02B01414D1 | [2] | SHIM,92mm ID x 160mm OD x 2mm Thk | KOB(2. 0) |
| C14. | YN02B01415D1 | [2] | SHIM,87mm ID x 150mm OD x 2mm Thk | KOB(2. 0) |
