Pos.	Part No	Qty	Parts name	Comments
.	23400-93C20	[1]	PISTON ASSY
1.	23411-93C20	[1]	PISTON	STD
1.	23411-93910	[6]	PISTON	OVER SIZE 0.50
1.	23411-93920	[6]	PISTON	OVER SIZE 0.75
1.	23411-93930	[6]	PISTON	OVER SIZE 1.00
.	23040-93C00	[1]	RING SET-PISTON	STD
N .	23040-93910	[1]	RING SET-PISTON	OVER SIZE 0.50
N .	23040-93920	[1]	RING SET-PISTON	OVER SIZE 0.75
N .	23040-93930	[1]	RING SET-PISTON	OVER SIZE 1.00
N2.	23431-93C10	[1]	RING-COMP 1	STD
N2.	23431-93910	[6]	RING-COMP 1	OVER SIZE 0.50
N2.	23431-93920	[6]	RING-COMP 1	OVER SIZE 0.75
N2.	23431-93930	[6]	RING-COMP 1	OVER SIZE 1.00
N3.	23432-93001	[6]	RING-COMP 2	STD
N3.	23432-93911	[6]	RING-COMP 2	OVER SIZE 0.50
N3.	23432-93921	[6]	RING-COMP 2	OVER SIZE 0.75
N3.	23432-93931	[6]	RING-COMP 2	OVER SIZE 1.00
N4.	23433-93000	[6]	RING-OIL	STD
N4.	23433-93910	[6]	RING-OIL	OVER SIZE 0.50
N4.	23433-93920	[6]	RING-OIL	OVER SIZE 0.75
N4.	23433-93930	[6]	RING-OIL	OVER SIZE 1.00
5.	23412-93000	[6]	PIN-PISTON
6.	23414-93000	[12]	RING-SNAP
.	23510-93050	[6]	CONNECTING ROD ASSY
7.	23511-93010	[6]	ROD-CONNECTING
N8.	23512-93000	[1]	CAP-CONNECTOR ROD
9.	23513-93030	[2]	BOLT
10.	23514-83000	[2]	NUT
11.	23517-93022	[1]	BUSHING-CONT ROD
11.	23517-93031	[1]	BUSHING-CONNECTING
12.	23610-93010	[1]	BEARING SET-CONN ROD	STD
12.	23010-93931	[AR]	BEARING SET-CONN ROD	UNDER SIZE 0.25
12.	23010-93932	[AR]	BEARING SET-CONN ROD	UNDER SIZE 0.50
12.	23010-93933	[AR]	BEARING SET-CONN ROD	UNDER SIZE 0.75
12.	23010-93934	[AR]	BEARING SET-CONN ROD	UNDER SIZE 1.00
