现代零件查询R210LC-7H(#9001-) TIMING GEAREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
160 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
23127-93000
|
[1] |
GEAR-CRANKSHAFT
|
|
| 2. |
24213-93000
|
[1] |
GEAR-CRANKSHAFT
|
|
| 3. |
23642-93000
|
[1] |
BOLT
|
|
| 4. |
23643-93000
|
[1] |
WASHER-CLAW
|
|
| . |
24610-93000
|
[1] |
IDLER ASSY 1
|
|
| 5. |
24611-93000
|
[1] |
GEAR-IDLER 1
|
|
| 6. |
24612-93000
|
[1] |
GEAR-IDLER 2
|
|
| 7. |
14530-05190
|
[1] |
KEY-WOODRUFF
|
|
| 8. |
26413-93000
|
[1] |
BUSHING
|
|
| 9. |
23640-93010
|
[1] |
SHAFT-IDLER 1
|
|
| 11. |
26414-93000
|
[1] |
BOLT
|
|
| . |
24630-93000
|
[1] |
IDLER ASSY 2
|
|
| N12. |
24631-93000
|
[1] |
GEAR-IDLER 2
|
|
| N13. |
24632-93000
|
[1] |
BUSHING
|
|
| 14. |
23641-93010
|
[1] |
SHAFT-IDLER 2
|
|
| 15. |
43215-69000
|
[2] |
BOLT-FLANGE
|
|
| 16. |
23644-93010
|
[2] |
WASHER-THRUST
|
|
| 17. |
14614-25000
|
[1] |
RING-SNAP
|
|
