现代零件查询R210LC-7H(#9001-) WATER PUMPEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
167 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
25100-93C00
|
[1] |
WATER PUMP ASSY
|
|
| N1. |
25116-93011
|
[1] |
CASE-WATER PUMP
|
|
| 2. |
15707-10171
|
[1] |
NIPPLE-GREASE
|
|
| N3. |
25121-93000
|
[1] |
IMPELLER
|
|
| N4. |
25126-93000
|
[1] |
SHAFT
|
|
| N5. |
25136-83000
|
[1] |
SEAL-UNIT
|
|
| 6. |
25142-72400
|
[1] |
BEARING-BALL
|
|
| 7. |
25141-72000
|
[1] |
BEARING-BALL
|
|
| N8. |
25137-72400
|
[1] |
WASHER
|
|
| 9. |
14615-62005
|
[1] |
RING-SNAP
|
|
| N10. |
25127-93000
|
[1] |
SPACER
|
|
| N13. |
25221-93C00
|
[1] |
PULLEY-WATER PUMP
|
|
| 14. |
13111-22001
|
[1] |
NUT-JAM
|
|
| 15. |
11514-10201
|
[6] |
STUD
|
|
| 16. |
25129-93000
|
[1] |
GASKET
|
|
| 17. |
11403-08301
|
[6] |
BOLT-FLANGE
|
|
| 17. |
11403-08221
|
[1] |
BOLT-FLANGE
|
|
