神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC128-01-2) - VALVE ASSY, CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
680 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY30V00037F1 | [1] | CONTROL VALVE | KOBAssy |
| . . | YY30V00037F2 | [1] | Control | |
| . . | YY30V00037F3 | [1] | CONTROL VALVE | KOBAssy |
| . . | YY30V00037F4 | [1] | CONTROL VALVE | KOBControl |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 2. | ZD12G03000 | [3] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 3. | 2436U1265S201 | [1] | COVER | KOB Superseded by part number: 2436U2631S201 |
| 4. | 2436U1265S203 | [1] | COVER | KOB |
| 5. | YY30V00031S262 | [1] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 6. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 7. | ZS23C08025 | [4] | SCREW,Hex Socket Head, M8 x 25mm | KOBCap |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONSpool (F1 ONLY) |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONSpool (F2 ONLY) |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONSpool (F3 ONLY) |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONSpool (F4 ONLY) |
| 12. | 2436U1265S327 | [1] | SPRING | KOB |
| 13. | 2436U1265S322 | [1] | SPRING | KOB |
| 14. | 2436U1265S335 | [1] | STOP | KOB |
| 15. | 2436U1265S336 | [1] | BOLT | KOBSpacer |
| 16. | 2436U1265S332 | [2] | SPRING SEAT | KOB |
| 17. | 2436U1197S512 | [1] | POPPET | KOB |
| 18. | 2436U1197S522 | [1] | SPRING | KOB |
| 19. | 2436U1485S552 | [1] | PLUG | KOB |
| 20. | ZD12P02200 | [1] | O-RING | KOB |
| 21. | YN22V00002F1 | [2] | VALVE | KOBAssy, Port Relief (See HC015) |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CONName Plate |
| 23. | NSS | [2] | NOT SOLD SEPARAT | CONPin |
