| . . | YN15V00037F1 | [1] | HYDRAULIC MOTOR | SM(propelling) Superseded by part number: YN15V00037F2 |
| . . | YN15V00037F2R | [1] | REMAN-HYD MOTOR | KOB200-8, SK210D-8, Both S/N YN11-45001 -, SK210DLC-8, SK210LC-8, Both S/N YQ11-06001 -, Reman For New P/N YN15V00037F1 |
| . . | YN15V00037F2C | [1] | CORE-MOTOR HYDRAULIC | KOBReturn Number |
| . . | YN15V00037F2 | [1] | HYDRAULIC MOTOR | KOBAssy (propelling) |
| 1. | YN15V00037S001 | [1] | HUB | KOB |
| 3. | YN15V00037S003 | [1] | FLANGE | KOBCarrier |
| 4. | YN15V00037S004 | [1] | GEAR | KOBSun |
| 5. | YN15V00037S005 | [3] | GEAR | KOBPlanetary |
| 6. | YN15V00037S006 | [3] | PIN | KOB |
| 7. | YN15V00037S007 | [1] | GEAR | KOBCarrier |
| 8. | YN15V00037S008 | [1] | GEAR | KOBSun |
| 9. | YN15V00037S009 | [3] | GEAR | KOBPlanetary |
| 10. | YN15V00037S010 | [3] | PIN | KOB |
| 11. | YN15V00037S011 | [6] | WASHER | KOBThrust |
| 12. | YN15V00037S012 | [6] | WASHER | KOBThrust |
| 13. | YN15V00037S013 | [1] | PLATE | KOB |
| 14. | YN15V00037S014 | [1] | COVER | KOB |
| 15. | YN15V00037S015 | [1] | COUPLING | KOB |
| 16. | YN15V00037S016 | [3] | PIN | KOB |
| 17. | YN15V00037S017 | [3] | PIN | KOB |
| 22. | YN15V00037S022 | [2] | LOCK WASHER | KOBLock Washer |
| 23. | YN15V00037S023 | [1] | SHIM | KOB |
| 24. | YN15V00037S024 | [2] | BALL BEARING | KOBBall |
| 27. | YN15V00037S027 | [3] | ROLLER BEARING | KOBNeedle |
| 28. | YN15V00037S028 | [3] | ROLLER BEARING | KOBNeedle |
| 29. | YN15V00037S029 | [1] | SEAL | KOBFloating |
| 30. | 2441U995S121 | [3] | PLUG | KOB |
| 31. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 35. | ZS23C10035 | [18] | SCREW,Hex Socket Head, M10 x 35mm | KOBCap |
| 36. | ZR26X03200 | [1] | SNAP RING | KOBRetaining |
| 101. | YN15V00037S101 | [1] | MANDREL | KOBSpindle |
| 102. | YN15V00037S102 | [1] | SHAFT | KOB |
| 103. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, Shoe |
| 104. | YN15V00037S104 | [1] | CYLINDER | KOBBlock |
| 105. | NSS | [9] | NOT SOLD SEPARAT | CONPiston |
| 106. | NSS | [9] | NOT SOLD SEPARAT | CONShoe |
| 107. | YN15V00037S107 | [1] | PLATE | KOBRetainer (For F1 ONLY) |
| . . | YN15V00037S098 | [1] | PLATE | KOBRetainer (For F2 ONLY) |
| 108. | YN15V00037S108 | [1] | BALL | KOBJoint (For F1 ONLY) |
| . . | YN15V00037S099 | [1] | BALL | KOBBall[ (For F2 ONLY) |
| 109. | YN15V00037S109 | [1] | PLATE | KOB |
| 112. | YN15V00037S112 | [1] | PISTON | KOB |
| 113. | YN15V00037S113 | [8] | SPRING | KOB |
| 114. | YN15V00037S114 | [9] | SPRING | KOB |
| 115. | YN15V00037S115 | [3] | PLATE | KOBFriction |
| 116. | YN15V00037S116 | [4] | PLATE | KOBSeparator |
| 119. | YN15V00037S119 | [1] | SHIM | KOB |
| 132. | YN15V00009S027 | [1] | OIL SEAL | KOB |
| 133. | YN15V00009S019 | [1] | RING | KOBRetaining |
| 135. | YN15V00037S135 | [1] | RING | KOB |
| 137. | 2436U279S3 | [1] | PLUG | KOB |
| 138. | 2436U1749S17 | [1] | PLUG | KOB |
| 139. | YN15V00037S139 | [1] | RING | KOB |
| 149. | YN15V00037S149 | [1] | ROLLER BEARING | KOBRoller Superseded by part number: 26799950 |
| 150. | YN15V00037S150 | [1] | ROLLER BEARING | KOBRoller Superseded by part number: YN15V00009S032 |
| 161. | NSS | [1] | NOT SOLD SEPARAT | CONPiston |
| 162. | YN15V00037S162 | [1] | BALL | KOB |
| 163. | NSS | [1] | NOT SOLD SEPARAT | CONSeal |
| 167. | NSS | [2] | NOT SOLD SEPARAT | CONPivot |
| 200. | YN22V00036F1 | [2] | VALVE | KOBAssy, Relief (See HC385) |
| 301. | YN15V00037S301 | [1] | FLANGE | KOB |
| 323. | NSS | [1] | NOT SOLD SEPARAT | CONSpool |
| 324. | YN15V00037S324 | [2] | PLUG | KOB |
| 325. | YN15V00037S325 | [2] | SEAT | KOBSpring |
| 326. | NSS | [2] | NOT SOLD SEPARAT | CONPlug |
| 327. | NSS | [2] | NOT SOLD SEPARAT | CONValve |
| 328. | NSS | [2] | NOT SOLD SEPARAT | CONSpring |
| 329. | YN15V00037S329 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB Superseded by part number: ZD12P03400 |
| 330. | YN15V00037S330 | [2] | SPRING | KOB |
| 331. | NSS | [2] | NOT SOLD SEPARAT | CONO-ring |
| 341. | YN15V00017S033 | [1] | PIN | KOB |
| 343. | ZS23C16040 | [8] | CAPSCREW,Hex Socket Head, M16 x 40mm | KOBSCREW Cap |
| 345. | 2436U1427S25 | [15] | PLUG | KOB |
| 363. | YN15V00037S363 | [1] | SPOOL | KOB |
| 364. | 2436R874S3 | [1] | FLEXIBLE JOINT | KOBConnector |
| 365. | 2436R874S6 | [1] | PIN | KOB |
| 366. | 2436R874S7 | [1] | SPRING | KOB |
| 367. | 2436R874S5 | [1] | SPRING SEAT | KOB |
| 368. | 2436U1317S13 | [2] | PLUG | KOB |
| 369. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 370. | LC15V00023S062 | [1] | PLUG | KOB |
| 371. | ZD12P01400 | [2] | O-RING | KOB |
| 372. | LC15V00023S067 | [2] | RESTRICTOR | KOB |
| 373. | LC15V00023S068 | [2] | SPRING | KOB |
| 374. | YN15V00017S038 | [5] | PLUG | KOB |
| 375. | ZD12P00800 | [6] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 376. | GN15V00010S024 | [3] | RESTRICTOR | KOB |
| 377. | YN15V00017S017 | [3] | CHECK VALVE | KOB |
| 378. | YN15V00017S026 | [3] | SPRING | KOB |
| 379. | ZD12P01600 | [1] | O-RING | KOB |
| 380. | YN15V00037S380 | [1] | O-RING | KOB |
| 397. | 2483U254S19 | [1] | Name Plate | |
| 398. | YN15V00037S398 | [4] | Rivet | |
| 399. | YN15V00037S399 | [1] | Name Plate | |
| . . | YN15V00037R400 | [1] | PISTON | KOBRepair Kit Consists Of Ref. 105x9, 106x9 |
| . . | YN15V00037R410 | [1] | PISTON | KOBRepair Kit Consists Of Ref. 161x1, 163x1 |
| . . | YN15V00037R420 | [1] | PLATE | KOBRepair Kit Consists Of Ref. 103x1, 167x2 |
| . . | YN15V00037R430 | [1] | VALVE | KOBRepair Kit Consists Of Ref. 103x1, 323x1, 324x2, 325x2, 326x2, 327x2, 328x2, 329x2, 330x2, 331x2, 341x1, 343x8, 345x15, 363x1, 364x1, 365x1, 366x1, 367x1, 368x2, 369x2, 370x1, 371x2, 372x2, 373x2, 374x5, 375x6, 376x3, 377x3, 378x3, 379x1, 380x1 |
| . . | YN15V00037R440 | [1] | VALVE | KOBRepair Kit Consists Of Ref. 323x1, 326x2, 327x2, 328x2, 331x2 |
| . . | YN15V00037R450 | [1] | SEAL KIT | KOBRepair Kit Consists Of Ref. 31x3, 132x1, 135x1, 139x1, 329x2, 369x2, 371x2, 375x6, 379x1, 380x1 |
| . . | YN15V00037R460 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 107x1, 108x1 (F2 Only) |
