神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC415-01-1) - VALVE ASSY, SOLENOID Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
984 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN35V00052F1 | [1] | VALVE | KOBAssy, Solenoid Superseded by part number: YN35V00054F1 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONSpool |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSleeve |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONSpring |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONRing, Retaining |
| 6. | YN35V00004S362 | [1] | O-RING | KOB |
| 7. | YN35V00004S363 | [1] | O-RING | KOB |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONSolenoid |
| 9. | YN35V00018S802 | [1] | NUT | KOB |
| 10. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONName Plate |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONName Plate |
