神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC680-63-1) - CYLINDER ASSY, ARM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
726 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN01V00181F1 | [1] | CYLINDER | KOBArm |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Cylinder |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONRod, Piston |
| 3. | YN01V00120S003 | [1] | CYLINDER HEAD | KOBCylinder Head |
| 4. | YN01V00120S004 | [1] | BUSHING | KOB |
| 5. | 2438U1171S5 | [1] | LOCKING RING | KOBSnap |
| 6. | YN01V00181S006 | [1] | RING | KOBBuffer |
| 7. | YN01V00181S007 | [1] | RING | KOB |
| 8. | YN01V00120S008 | [1] | RING | KOBBack Up |
| 9. | YN01V00120S009 | [1] | RING | KOBWiper |
| 10. | ZD12G16000 | [1] | O-RING,159.30mm ID x 170.70mm OD x 5.70mm | KOB |
| 11. | 2438U1171S11 | [1] | BACK-UP RING | KOB |
| 12. | LC01V00005S012 | [12] | SCREW | KOBCap |
| 13. | YN01V00120S013 | [1] | RING | KOBCushion |
| 14. | YN01V00120S014 | [1] | SEAL | KOBCushion |
| 15. | YN01V00120S015 | [1] | PISTON | KOB |
| 16. | 2438U1171S16 | [1] | SEAL | KOBRing |
| 17. | 2438U1171S17 | [2] | BACK-UP RING | KOB |
| 18. | LC01V00054S018 | [2] | RING | KOBSlide |
| 19. | 2438U1171S19 | [2] | RING | KOBSlide |
| 20. | YN01V00120S020 | [1] | SHIM | KOB |
| 21. | 2438U1171S22 | [1] | SET SCREW | KOBSet |
| 22. | 2436U330S27 | [1] | BALL | KOB |
| 23. | YN01V00120S023 | [1] | RING | KOBCushion |
| 24. | LC01V00005S025 | [1] | SEAL | KOBCushion |
| 25. | 2438U1137S26 | [2] | STOP | KOB |
| 26. | 2438U1171S27 | [1] | LOCKING RING | KOBSnap |
| 27. | YN01V01084P1 | [1] | BUSHING | KOB |
| 28. | YN01V00120S028 | [2] | RING | KOB |
| 29. | YN01V01085P1 | [1] | BUSHING | KOB |
| 30. | YN01V00120S030 | [2] | RING | KOB |
| . . | YN01V00181R100 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 6x1, 7x1, 8x1, 9x1 |
| . . | YN01V00181R200 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 14x1, 16x1, 17x2 |
| . . | YN01V00181R300 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 6x1, 7x1, 8x1, 9x1 |
| . . | YN01V00181R400 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 1x1, 27x1, 28x2 |
| . . | YN01V00181R500 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 2x1, 29x1, 30x2 |
