| . . | YX01V00005F6 | [1] | CYLINDER,Double Acting, 65mm Rod, 885mm Stroke | KOBAssy, Bucket |
| . . | YX01V00005F6R | [1] | REMAN-HYD CYLINDER | RACSK210D-8, 200-8, BOTH S/N YN11-45001 -, SK210DLC-8, SK210LC-8, BOTH S/N YQ11-06001 - |
| . . | YX01V00005F6C | [1] | CORE-HYD CYLINDER | RACReturn number |
| . . | YX01V00005F7 | [1] | HYDRAULIC CYLINDER | KOBAssy, Bucket |
| . . | YX01V00005F7R | [1] | REMAN-HYD CYLINDER | RAC200-8, SK210D-8, Both S/N YN11-45001 -, SK210DLC-8, SK210LC-8, Both S/N YQ11-06001 - |
| . . | YX01V00005F7C | [1] | CORE-HYD CYLINDER | RACReturn Number |
| . . | YX01V00005F8 | [1] | BUCKET CYLINDER | KOBAssy, Bucket |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Cylinder (F8 ONLY) |
| 2. | 2438U1097S2 | [2] | BUSHING | KOBBushing (F7, F8 ONLY) |
| 3. | 2438U1097S29 | [4] | SEAL | KOBDust |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONRod, Piston |
| 5. | YW01V00003S029 | [1] | PISTON | KOB |
| 6. | YW01V00001S008 | [1] | O-RING | KOB |
| 7. | YW01V00001S009 | [2] | BACK-UP RING | KOB |
| 8. | YW01V00003S030 | [1] | SEAL | KOBPiston Superseded by part number: YW01V00001S031 |
| 9. | YW01V00001S032 | [2] | RING | KOBWear |
| 10. | YW01V00001S012 | [2] | RING | KOB |
| 11. | YW01V00001S013 | [1] | NUT | KOBPiston |
| 12. | YN01V00001S014 | [1] | SCREW | KOBSet |
| 13. | YX01V00005S013 | [1] | RING | KOBCushion |
| 15. | 2438U1097S18 | [1] | BUSHING | KOB |
| 16. | B38K0038E10 | [1] | CLIP | KOB |
| 17. | ZD12G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOB |
| 18. | YW01V00001S020 | [1] | RING | KOBBack Up |
| 19. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOBO-Ring |
| 23. | ZS23C14065 | [8] | BOLT,Hex Socket Head, M14 x 65mm | KOBCapscrew |
| 24. | YW01V00003S024 | [1] | BRACKET | KOBBand |
| 25. | YW01V00003S025 | [1] | BRACKET | KOBBand (F6, F7 ONLY) |
| . . | YW01V00003S025 | [2] | BRACKET | KOBBand (F8 ONLY) |
| 26. | ZS16C10030 | [2] | CAPSCREW | KOBSCREW Cap (F6, F7 ONLY) Superseded by part number: ZS18C10030 |
| . . | ZS16C10030 | [4] | CAPSCREW | KOBSCREW Cap (F8 ONLY) Superseded by part number: ZS18C10030 |
| 27. | ZW26X10000 | [2] | LOCK WASHER | KOB(F6,F7 ONLY) |
| . . | ZW26X10000 | [4] | LOCK WASHER | KOB(F8 ONLY) |
| 28. | YX01V00005S028 | [1] | BAND | KOB(F8 ONLY) |
| 29. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Cylinder (F6, F7 ONLY) |
| 30. | YN01V01086P1 | [1] | BUSHING,60mm ID x 80mm OD x 70mm L | KOB(F6 ONLY) |
| 31. | YN01V01092P1 | [1] | BUSHING,60.2mm ID x 70mm OD x 80mm L | KOB(F6 ONLY) |
| 32. | YX01V00005S032 | [1] | COVER | KOBRod |
| 33. | YY01V00005S029 | [1] | SEAL | KOB |
| 34. | YY01V00005S030 | [1] | PACKING | KOBRod |
| 35. | YY01V00005S031 | [1] | BACK-UP RING | KOB |
| 36. | YY01V00005S032 | [1] | SEAL | KOBDust Superseded by part number: 2438U807S15 |
| 37. | B38K0039E11 | [1] | CLAMP | KOBClip |
| . . | YX01V00005R200 | [1] | REPAIR KIT | KOBPiston Side Superseded by part number: YW01V00003R200 |
| . . | YX01V00005R400 | [1] | TUBE | KOBRepair Kit Consists Of Ref. 1x1, 2x1 (F8 ONLY) |
| . . | YX01V00005R500 | [1] | PISTON ROD | KOBRepair Kit Consists Of Ref. 2x1, 4x1 (F7, F8 ONLY) |
| . . | YX01V00005R600 | [1] | TUBE | KOBRepair Kit Consists Of Ref. 2x1, 29x1 (F7 ONLY) |
| . . | YX01V00005R800 | [1] | REPAIR KIT | KOBConsists Of Ref. 29x1, 30x1 (F6 ONLY) |
| . . | YX01V00005R900 | [1] | REPAIR KIT | KOBPiston Rod Kit, Consists Of Ref. 4x1, 31x1 (F6 ONLY) |
| . . | YY01V00005R600 | [1] | REPAIR KIT | KOBRod Side, Consists Of Ref. 17x1, 18x1, 19x1, 33x1, 34x1, 35x1, 36x1 |
| . . | YY01V00005R700 | [1] | REPAIR KIT | KOBAll (Rod + Piston) Consists Of Ref. 6x1, 7x2, 8x1, 9x2, 10x2, 17x1, 18x1, 19x1, 33x1, 34x1, 35x1, 36x1 |
