凯斯零件查询(FLX3010) - FLOATER (8/04-8/06) (02-015) - AIR EXHAUST GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
629 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87266036
|
[1] |
MOUNTING PLATE
|
BN
Exhaust
|
| 2. |
BN311344
|
[1] |
MUFFLER
|
BN
Assembly, 18-2450 CFM Superseded by part number: BN313594, BN313591, BN313590, 84289019, BN313588, BN313589
|
| 3. |
87266694
|
[1] |
ELBOW
|
BN
Exhaust, Turbo
|
| 4. |
86986686
|
[1] |
EXHAUST SYSTEM PIPE
|
BN
Stack, 36" Curved
|
| 5. |
87268064
|
[1] |
ELBOW
|
BN
90º 5" OD
|
| 6. |
413677A1
|
[1] |
TUBE
|
CAS
Flexible, Exhaust
|
| 7. |
BN313588
|
[1] |
SHIELD
|
BN
Heat, Muffler
|
| 8. |
BN313590
|
[2] |
CLAMP
|
BN
Heat Shield
|
| 9. |
87266037
|
[1] |
TUBE,42 mm DIA
|
BN
Pre-Cleaner
|
| 10. |
86629541
|
[6] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 11. |
100038
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 12. |
614-10040
|
[4] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120112
|
| 13. |
100037
|
[7] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 14. |
A170807
|
[1] |
CLAMP,102mm ID
|
CAS
4" T-Bolt
|
| 15. |
BN313592
|
[2] |
CLAMP
|
BN
Bent Bolt, 5" Superseded by part number: 84289019
|
| 16. |
413678A1
|
[2] |
CLAMP,129.03mm ID
|
CAS
Assembly, Flexible Exhaust
|
| 17. |
334985A1
|
[1] |
CLAMP
|
CAS
Exhaust
|
| 18. |
86637998
|
[1] |
CLAMP,38.1mm, Coat, 10.3mm Bolt Hole, P Type
|
FAR
|
| 19. |
11106231
|
[3] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 20. |
BN313589
|
[6] |
BOLT
|
BN
Heat Shield
|
| 21. |
43128
|
[2] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 22. |
86528579
|
[2] |
NUT,M8 x 1.25
|
WIN
|
| 23. |
86624184
|
[4] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 24. |
86625252
|
[10] |
WASHER,10.8mm ID x 21.5mm OD x 2.5mm Thk
|
FAR
|
| 25. |
86625255
|
[12] |
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
|
GI
|
| 26. |
BN306386
|
[1] |
CLAMP,129.5mm ID
|
BN
Muffler 5’’, Yellowzink Plated
|
| 27. |
87268766
|
[1] |
BRACKET
|
BN
Exhaust Elbow, 3 Wheel
|
| 28. |
86625253
|
[4] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
