神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (ENG-02-2) - CYLINDER BLOCK Kobelco

广数供应链运营团队, 15 02月, 2025,浏览: 933 次

格莳国际 工程机械 重卡 农机 汽配
Pos.Part NoQtyParts nameComments
11401. VH11401E0701 [1]  BLOCK KOBBlock Sub Assy, Cyl (Uses Cylinder Liners with 8mm flange Height) Superseded by part number: VH11401E0704
11408. VH114081400A [4]  PIPE KOBSub Assy, Oil Jet Superseded by part number: VHS114081400
11409. VH11409E0190 [1]  GUIDE KOBSub Assy, Oil Level Gage
11467. VH114673200A [4]  LINER KOBCyl, S/S (A) (Flange height 8mm) (Refer to Service Manual for Size) Superseded by part number: VHS114673200
11467. VH114673210A [4]  LINER KOBCyl, S/S (B) (Flange height 8mm) (Refer to Service Manual for Size) Superseded by part number: VHS114673210
11467. VH114673220A [4]  LINER KOBCyl, S/S (C) (Flange height 8mm) (Refer to Service Manual for Size) Superseded by part number: VHS114673220
11521. VH115211261A [10]  BOLT KOBBearing Cap Superseded by part number: VHS115211261
12111. VH12111E0061 [1]  PAN KOBPan.Oil
12149. VH121491030A [1]  VALVE KOBOil Drain Superseded by part number: VHS121491030
12151. VH12151E0020 [1]  GASKET KOBOil Pan
15117. VH151171170A [1]  BUSHING KOBBody Oil Pump Superseded by part number: VHS151171170
15301. VH15301E0020 [1]  LEVEL GAUGE KOBSub-Assy, Oil Level Superseded by part number: VH15301E0022
15605. VH156051250A [4]  VALVE KOBSub Assy, Oil Check Superseded by part number: VHS156051250
79904. VH799041220A [2]  CLIP KOBSub Assy Superseded by part number: VHS799041220
82702. VH82702E0E80 [1]  BRACKET KOBSub Assy, Wiring Harness
9068-08160. VH906808160A [2]  FLANGE BOLT KOBFlange Superseded by part number: VHSH55210816
9068-08800. VH906808800A [2]  BOLT KOBFlange Superseded by part number: VHSH55210880
9068-10180. VH906810180A [1]  BOLT KOBFlange Superseded by part number: VHSH55211018
9069A. VH906908181A [24]  BOLT KOBFlange
9069B. VH906912122A [4]  BOLT KOBFlange (L=40) Superseded by part number: VHSZ10512023
9069C. VH906914105A [4]  BOLT KOBFlange (L=60) Superseded by part number: VHSZ10514018
9240-08087. VH924008087A [1]  NUT KOB Superseded by part number: VHSL15010808
9509A. VH950908122A [11]  PIN KOB Superseded by part number: VHSZ25008007
9509B. VH950908123A [2]  PIN KOB Superseded by part number: VHSZ25008008
9600-12090. VH960012090A [1]  PLUG KOB Superseded by part number: VHSN46001209
9619A. VH961918113A [1]  PLUG KOB Superseded by part number: VHSZ34118014
9633-17120. VH963317120A [5]  PLUG KOBSealing Superseded by part number: VHSN41101712
9633-22160. VH963322160A [2]  PLUG KOBSealing Superseded by part number: VHSN41102216
9633-26160. VH963326160A [4]  PLUG KOBSealing Superseded by part number: VHSN41102616
9633-30160. VH963330160A [1]  PLUG KOBSealing Superseded by part number: VHSN41103016
9633-50160. VH963350160A [4]  PLUG KOBSealing Superseded by part number: VHSN41105016
9639A. VH963942104A [3]  PLUG KOBExpansion Superseded by part number: VHSZ33142002
9659A. VH965918105A [2]  WASHER KOBSoft Superseded by part number: VHSL72301814
9659B. VH965912111A [1]  WASHER KOBSoft Superseded by part number: VHSL72301210
9851A. VH985110138A [1]  O-RING KOB Superseded by part number: VHSZ30110025
