神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (ENG-03-1) - TIMING GEAR COVER AND FLYWHEEL HOUSING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
487 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11306. | VH113061480A | [1] | COVER ASSY | KOBSub, F/H Dust Superseded by part number: VHS113061480 |
| 11309. | VH11309E0010 | [1] | RETAINER | KOBSub Assy, Oil Seal |
| 11351. | VH11351E0272A | [1] | HOUSING | KOBFlywheel Superseded by part number: VH11351E0272 |
| 11357. | VH113571022A | [1] | GASKET | KOBRr End Plate Superseded by part number: VHS113571022 |
| 11357A. | VH113571062A | [1] | GASKET | KOBRr End Plate Superseded by part number: VHS113571062 |
| 11390. | VH113901090A | [1] | PLATE | KOBRr End Superseded by part number: VHS113901090 |
| 12281. | VH122811901A | [1] | HANGER | KOBEng Superseded by part number: VHS122811901 |
| 900113A. | VH900113120A | [4] | INSERT | KOBHelisert Superseded by part number: VHSZ91013008 |
| 900124. | VH900124540A | [2] | BOLT | KOB Superseded by part number: VHSZ91024292 |
| 9029A. | VH902910281A | [2] | BOLT | KOB Superseded by part number: VHSZ11010007 |
| 9068-08000. | VH906808000A | [1] | BOLT | KOBFlange Superseded by part number: VHSH55210800 |
| 9068-08250. | VH906808250A | [5] | FLANGE BOLT | KOBFlange Superseded by part number: VHSH55210825 |
| 9068-10200. | VH906810200A | [3] | BOLT | KOBFlange Superseded by part number: VHSH55211020 |
| 9068-10750. | VH906810750A | [2] | BOLT | KOBFlange Superseded by part number: VHSH55211075 |
| 9068-60850. | VH906860850A | [1] | BOLT | KOBFlange Superseded by part number: VHSH55216085 |
| 9069G. | VH906908149A | [2] | BOLT | KOBFlange Superseded by part number: VHSZ10508055 |
| 9181-08160. | VH918108160A | [2] | BOLT | KOB Superseded by part number: VHSH68100816 |
| 9241-10107. | VH924110107A | [1] | NUT | KOB Superseded by part number: VHSL15041010 |
| 9339A. | VH933910115A | [1] | STUD | KOB Superseded by part number: VHSZ11610047 |
| 9349A. | VH934914128A | [1] | STUD | KOB Superseded by part number: VHSZ11614025 |
| 9402-12350. | VH940212350A | [2] | BOLT,M12 x 35mm | KOBW/Washer Superseded by part number: VHSH78241235 |
| 9419A. | VH941916101A | [4] | BOLT | KOB Superseded by part number: VHSZ11916013 |
| 9828A. | VH982879103A | [1] | SEAL | KOBOil Superseded by part number: VHSZ31179002 |
| 9828B. | VH982801228A | [1] | SEAL | KOBOil Superseded by part number: VHSZ31101045 |
