神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (ENG-04-1) - CAMSHAFT AND IDLE GEAR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
822 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 13501. | VH135011610A | [1] | CAMSHAFT | KOBSub Assy Superseded by part number: VH13501E0240 |
| 13505. | VH135052360A | [1] | GEAR | KOBSub Assy, Idle Superseded by part number: VH13508E0660 |
| 13505A. | VH135052292A | [1] | GEAR | KOBSub Assy, Idle Superseded by part number: VH13508E0590 |
| 13505B. | VH135052521A | [1] | GEAR | KOBSub Assy, Idle Superseded by part number: VH13508E0331 |
| 13520. | VH135201090A | [1] | GEAR | KOBAssy, Camshaft Superseded by part number: VHS135201090 |
| 13572. | VH135721250A | [1] | PLATE | KOBIdle Gear Thrust Superseded by part number: VHS135721250 |
| 13572A. | VH135721230A | [1] | PLATE | KOBIdle Gear Thrust Superseded by part number: VHS135721230 |
| 13572B. | VH135721271A | [1] | PLATE | KOBIdle Gear Thrust Superseded by part number: VHS135721271 |
| 13581. | VH135811711A | [1] | SHAFT | KOBIdle Gear Superseded by part number: VH13581E0190 |
| 13581A. | VH135811530A | [1] | SHAFT | KOBIdle Gear Superseded by part number: VHS135811530 |
| 13581B. | VH135811440A | [1] | SHAFT | KOBIdle Gear Superseded by part number: VHS135811440 |
| 900124. | VH900124503A | [1] | BOLT | KOB Superseded by part number: VHSZ91024265 |
| 900124A. | VH900124502A | [2] | BOLT | KOB Superseded by part number: VHSZ91024264 |
| 900125. | VH900125101A | [1] | BOLT | KOB Superseded by part number: VHSZ91024338 |
| 9509A. | VH950906123A | [1] | PIN | KOB Superseded by part number: VHSZ25006005 |
| 9509B. | VH950906124A | [1] | PIN | KOB Superseded by part number: VHSZ25006006 |
| 9867A. | VH986750134A | [1] | BUSHING | KOB Superseded by part number: VHSZ38450014 |
| 9867B. | VH986757106A | [1] | BUSHING | KOB Superseded by part number: VHSZ38457002 |
