凯斯零件查询(FLX3010) - FLOATER (8/04-8/06) (08-001) - HARNESS ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
472 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN325082
|
[1] |
WIRE HARNESS
|
BN
RH Console, No Bed
|
| 2. |
BN325109
|
[1] |
WIRE HARNESS
|
BN
RH Compartment, No Bed
|
| 3. |
87265862
|
[1] |
WIRE HARNESS
|
BN
Rear Frame 535
|
| 4. |
87265918
|
[1] |
WIRE HARNESS
|
BN
Engine
|
| 5. |
87265863
|
[1] |
WIRE HARNESS
|
BN
Front Frame 535
|
| 6. |
87270251
|
[1] |
WIRE HARNESS
|
BN
Front Headlight
|
| 7. |
87265150
|
[1] |
WIRE HARNESS
|
BN
Adapter C WKLS
|
| 8. |
342804A1
|
[1] |
WIRE HARNESS
|
BN
Rear Tail Light
|
| 9. |
342805A1
|
[1] |
WIRE HARNESS
|
BN
Derate/Flexair Only
|
| 10. |
86986654
|
[1] |
WIRE HARNESS
|
BN
Extention, Taillight
|
| 11. |
87265143
|
[1] |
WIRE HARNESS
|
BN
Remote Jumper
|
