凯斯零件查询(FLX3010) - FLOATER (8/04-8/06) (08-002) - FRAME ELECTRICAL GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
637 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
178149A1
|
[1] |
SOLENOID SWITCH
|
CAS
Kit, With Barrier, Starter Relay
|
| . . |
NS
|
[1] |
NOT SERVICED
|
BAS
EXT., Rear Lights, Start Serial: 6700
|
| . . |
343668A1
|
[1] |
WIRE HARNESS
|
BN
Headlight EXT.
|
| . . |
614-6025
|
[6] |
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86977786
|
| . . |
353308
|
[6] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| . . |
87265862
|
[1] |
WIRE HARNESS
|
BN
Rear Frame 535, Start Serial: 6700
|
| . . |
87265916
|
[1] |
WIRE HARNESS
|
BN
Rear Frame 535
|
| . . |
87265863
|
[1] |
WIRE HARNESS
|
BN
Front Frame 535, Start Serial: 6700
|
| . . |
87265917
|
[1] |
WIRE HARNESS
|
BN
Front Frame 535
|
| . . |
86588450
|
[6] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| . . |
BN323590
|
[1] |
HARNESS
|
BN
Back-Up
|
| . . |
87269427
|
[1] |
WIRE HARNESS
|
BN
EXT, Rear Lights
|
| . . |
342190A1
|
[1] |
DECAL
|
BN
Bulkhead Callout
|
| . . |
87270251
|
[1] |
WIRE HARNESS
|
BN
Front Headlight
|
